Clutch Alignment Tool Allis Chalmers B C CA D10 D12 D14 D15

Clutch alignment tool for Allis Chalmers B, C, CA, IB, D10, D12, D14, D15, H3, HD3, I500, and I600.

Plastic tool that fits both 8-1/2" and 9" clutch assemblies.

Part Number: DJS14522

Fits

• Allis Chalmers B
• Allis Chalmers C
• Allis Chalmers CA
• Allis Chalmers IB (early models with 9" diameter standard, not H.D., clutch assembly)
• Allis Chalmers D10 (up to SN 3501, early models with 9" diameter standard, not H.D., clutch assembly)
• Allis Chalmers D12 (up to SN 3001, early models with 9" diameter standard, not H.D., clutch assembly)
• Allis Chalmers D14
• Allis Chalmers D15
• Allis Chalmers H3
• Allis Chalmers HD3
• Allis Chalmers I500
• Allis Chalmers I600

Specs

• Plastic
• Fits both 8-1/2" and 9" clutch
• 1-1/8" x 10 spline
• Pilot .575"
