Description
Delco Distributor Terminal Insulator Assembly, Square Style
Important: AB-500D is a square-style Delco distributor terminal insulator assembly. It is for Delco distributors only and will not fit IH built distributors/magnetos.
Fits
- Allis-Chalmers B, C, CA, D10, D12, D14, D15, D17, D19, IB, RC, WC, WD, WD45, WF (with Delco distributor)
- Avery
- Case 400B (with Delco distributor numbers 1111908, 1111909), D, DC, DC-3, DC-4, DCS, DEX, DH, DI, DI/NAR, DO, DO-VS, DO/STD, DOEX, DV, S, SC, SC-3, SC-4, SI, SO (wi/1111411 Delco vertical distributor)
- Cockshutt 550, 570
- Oliver Built
- International A, AV, B, BN, C, H, HV, I6, M, MV, O4, O6, Super A, Super C, Super H, Super M, Super MV, T6, W4, W6
- John Deere A, B, G, H, 50, 60, 70, 420, 430, 440, 520, 530, 620, 630, 720, 730, 1010, 2010, 3010, 4010
- Massey Ferguson Super 90, TO35, 65, 85, 88, 95, 97, 204, 302, 304, 356, 470, MF Tractor 35, Ferguson 40, MF Ag Tractor 50, Industrial 202, Ferguson Tractor TO30
- Massey Harris 50
- Oliver Super 55, Super 66, Super 77, Super 88, 550, 660, 770, 880 (using Delco distributor numbers 1112603, 1900, OC4), 1800 (some - using Delco distributor numbers 1112603, 1900, OC4)
- White
Replaces / Cross Reference
- Allis-Chalmers: 225794, 225792, 225795, 225793, 225791
- Avery: 1916805, 817363, 1914144, 1914142, 1916806, 120622
- Case: 817363, 1914142, 1916805, 120622, 1916806, 1914144
- Cockshutt: MA627, MA626, MA628, MA629, MA467, MA624, MA625
- International: 817363, 120622, 1916805, 1916806, 1914142, 1914144
- John Deere: 817363, 1909206, 12H290R, 1916806, 1914142, 1916805
- Massey Ferguson: 354119X, 1750514M1, 1750520M1, 353444XL, 22303X
- Oliver: 1H7437, 1K7445, 1K7434A, 1H7431, 1K7430, 7A7820, 1K7433
Notes
- Distributors may be changes throughoput the years; check which style you need
- Square style is the late style that fit distributor housings with .300 Dia hole with a keyway
- Condition: New
