Oil seal for the listed Allis-Chalmers, Case, Ford, IH/Farmall, and John Deere applications. Verify fitment by model and notes before ordering.
Part Number: AB-1543D
Fits
- Allis Chalmers: PTO output shaft retainer seal on WC, WF, RC
- Allis Chalmers: PTO gearbox stub shaft seal prior to 1935 on WC, WF
- Allis Chalmers: belt pulley drive seal on WC (prior to sn 74330), WF (up to sn 1336)
- Allis Chalmers: outer differential shaft oil seal on D10, D12, D14, D15
- Allis Chalmers Industrials: 500, 510, 512, 600, 610, 612, 614, 615, 621, I60, I600; 2 used per tractor, sold individually
- Case: standard non-live PTO seal on VA, VAC, VAH, VAI, VAO, 200B, 210B, 211B, 300B, 310B, 311B, 312B, 320B, 350, 351, 420B, 430, 431, 440, 441, 470, 480, 500B, 510B, 511B, 530, 531, 540, 541, 570, 580, 630
- Ford: NAA, Jubilee as a pinion shaft seal
- IH / Farmall: live PTO oil seal on SMTA, 300, 330, 340, 350, 400, 450, 460, 504, 560, 606, 660, W400, W450
- IH / Farmall: transmission driven PTO seal on 404, 2404
- John Deere: outer brake pinion shaft outer seal on 1010, 2010; 2 used per tractor, sold individually
Specs
- I.D.: 1.375
- O.D.: 2.378
- Width: .312
Replaces / Cross Reference
- Allis Chalmers: 70206786, 70244961
- Case: VT3520, G13803
- Ford: NAA4676A
- International Harvester: 359051R91, 360436R91, 364472R91, 364477R91
- John Deere: AM2924T, AT12540
- abc1543
