Allis Chalmers WD45 Brake Parts

Allis Chalmers - WD, WD45, WD45 (diesel), D17 (up to SN: 42000) ** Brake Pin must have at least half of the head remaining for the puller to function properly.**

ITEM # AC-2678D Allis Chalmers - WD, WD45, WD45 (Diesel); Replacement for - 70222650 cross reference ACS2678

Allis Chalmers - D17 (Up to SN: 42000), WD, WD45 (Gas & Diesel) Replacement for: 70232585, 70227502, 70218573 2 used per tractor, sold individually improved ductile iron 1-1/2" bore with keyway, 2.860 wide, 7.875 O.D.

Allis Chalmers - WD, WD45, D17 (up to sn 42000)0.752" OD - 6-5/8" Overall length - 2 used per tractor - sold in set of 2- USA MADEReplaces: 217599, 232801, 70217599, 70232801STAINLESS STEEL

Allis-Chalmers Brake Anchor Shoe PinPart Number: AC-1191DBrake anchor shoe pin for Allis-Chalmers WD, WD45, and D17 models up to serial number 42000.FitsAllis-Chalmers WDAllis-Chalmers WD45Allis-Chalmers D17 up to sn 42000Replaces / Cross...

Allis-Chalmers Rear Brake Shoe Return Spring 70222501Rear brake shoe return spring for Allis-Chalmers WD, WD45, and D17 up to serial number 42000. Measures 3 1/4" long and is sold individually. Two are used per tractor.FitsAllis-Chalmers...

Allis-Chalmers Front Brake Spring 70232564Fits Allis-Chalmers WD, WD45, D17, and D19. This front brake spring is 3" long and is sold individually. Two are used per tractor.FitsAllis-Chalmers WDAllis-Chalmers WD45Allis-Chalmers D17Allis-Chalmers...

Allis Chalmers WD, WD45 Brake Rod Return Spring6-5/8" long. Sold individually. 2 used per tractor.This brake rod return spring fits Allis Chalmers WD and WD45 tractors and replaces part numbers 222670 and 70222670.FitsAllis Chalmers WDAllis Chalmers...

Allis-Chalmers Brake Lining KitFor Allis-Chalmers WD, WD45, WD45 Diesel, and D17 up to SN 42000. This 6-1/2" long kit lines one wheel.FitsAllis-Chalmers WDAllis-Chalmers WD45Allis-Chalmers WD45 DieselAllis-Chalmers D17 up to SN 42000Replaces / Cross...
