Description
Valve train kit for Allis-Chalmers D17, 170, and 175 applications listed below.
Includes valves, guides, springs, and keepers. Retainers are not included.
Part Number: VTKACD17
Fits
- AC Combines - [ E, EII, EIII, SP110, Super 100 (with G226 4-cylinder gas, LP engines with cylinder head casting # AM4469 or AM4472:)]
- AC Miscellaneous - The following with G226 4-cylinder gas, LP engines with cylinder head casting # AM4469 or AM4472: 616 (Cotton Picker), [ 707, 707XTB (Cotton Harvester) ], D (Motor Grader; SN: 5425 and up), [ DG, M65 (Motor Grader) ], [ G226, W226 (Power Unit) ], TL10 (Loader; late serial numbers), [ TL11, TL12 (Loader) ]
- Allis Chalmers - [170, 175, D17 (the following with G226 4-cylinder gas, LP engines with cylinder head casting # AM4469 or AM4472:)]
Replaces / Cross Reference
- Valve spring: 206879, 70206879
- Valve locks / keepers: 209103, 70209103
- Exhaust guide: 229911, 70229911
- Exhaust valve: 241527, 70241527
- Intake valve: 241535, 70241535
- Intake guide: 241536, 70241536
Specs
- Keeper groove width: 0.100"
- Intake valve seat angle: 30 degrees
- Exhaust valve seat angle: 45 degrees
Notes
Does not include retainers.
Details
Replaces / Cross Reference: |
206879; 70206879; 209103; 70209103; 229911; 70229911; 241527; 70241527; 241535; 70241535; 241536; 70241536 |
Keeper Groove Width: |
0.100 in. |
Intake Valve Seat Angle: |
30 degrees |
Exhaust Valve Seat Angle: |
45 degrees |
Part Type: |
Valve train kit |
