Allis Chalmers Zenith Style Carburetor

New Zenith style carburetor replacement with listed fitment and cross references.

Part Number: AB-223D

Fits

• Allis Chalmers: B, IB, C, CA (1952-56), D10, D12, WC, WD, WF
• Avery: A
• Case: VA (1942-56), V, VAC, VC, VAI, VAS, VAO, VAH, SC, SI, SO
• IH / Farmall: A, AV, B, BN, C, Super A, Super C, 100, 130, 140, 200, 230, 240, 330, 340,500 Crawler, I- 340, F- 404 and I- 404 Crawlers: T340, T4 Crawler, T5, Windrower U-2, 201
• John Deere: L (sn L640000 and up), LA, LI --- Power units: LUC --- Combines: 12A, 25, 30
• Massey Ferguson: TO20, 30, 81, 82, 101 JR., 102 Jr, F-162 Continental engines, 60 PT Combine
• MM: BF, BFH, BG, R-RT (1945-52), RT (1939-48), RTI
• Oliver: 15 Grain Master, 35SP Combine, HG, OC-3, 44, 60, 66, 70, 77 IXB-3 Hercules engine, 15 Grain Master, 35SP Combine

Specs

• New, Zenith Style replacement
• 2-5/16" to 2-3/8" CC stud holes (Because of the smaller dia studs that are included)
• Length = 4.88"
• Some applications you must trim throttle shaft to clear the block

Replaces / Cross Reference

• Carb MFG: Marvel Schebler: TSX21, TSX28, TSX30, TSX34, TSX36, TSX42, TSX43, TSX55, TSX60, TSX69, TSX74, TSX88, TSX90, TSX114, TSX120, TSX138, TSX154, TSX155, TSX156, TSX157, TSX159, TSX171, TSX186, TSX188, TSX198, TSX212, TSX231, TSX248, TSX253, TSX272, TSX287, TSX305, TSX308, TSX309, TSX312, TSX333, TSX346, TSX347, TSX348, TSX359, TSX361, TSX361A, TSX363, TSX380, TSX400, TSX403, TSX405, TSX406, TSX418, TSX421, TSX422, TSX447, TSX470, TSX474, TSX472, TSX486, TSX507, TSX513, TSX541, TSX606, TSX665, TSX668, TSX670, TSX701, TSX730, TSX744, TSX748, TSX809, TSX815, TSX827, TSX860, TSX926
• ZENITH: 3199, 9705, 9706, 9707, 9749, 9752, 9797, 9804, 10514, 11115, 11141, 11142, 12115, 12122, 12225, 12285, 12401, 12475, 12522, 12566, 12262, 12749, 12773, 12911, 14544, 16232
• Allis Chalmers: 222038, 219966
• Case: VT2072, VT2475, VT2632, VT3593, VT4062, VTA976
• International Harvester: 69402D, 96401D, 352047R91, 69404D, 372985R92
• John Deere: AL2283T, AL2630T, AL2848T, AL2851T, AL2859T, AL2850T, AL20225T, AL20290T
• Massey Ferguson: 181643M91, 181644M91
• Massey Harris: 6195A, 6371A, 6307A, 6401A, 6683A, 6684A, 761301M91, 761304M91
• MM: EE733, EE733A, 10A1329
• Avery: 135119, 120320
• Oliver: HS393A, HS393B, BS393K, MS393, MS393A, C116911, 151432, C117144, LS393A, 117834

Notes

• Condition: New
• NO REFUNDS OR REPLACEMENTS WILL BE GIVEN IF WE FIND ANY DIRT, RUST, CONTAMINATION INSIDE THE CARBURETOR OR IF THE CARBURETOR HAS BEEN TAKEN APART.
