Rim Wheel Lug Bolt 9/16-18

Rim wheel lug bolt with 9/16" x 18 UNF thread, 1 1/8" long thread, and 7/8" hex head.

Part Number: AB-397D

Fits

Allis Chalmers - Rear: WD, WD45, D10, D12, D14, D15, D17, 170, 175, 180, 185, I-40, I-60, I-400, I-600

Avery - Rear: A, R, BF, BG

Case - Rear: 200B, 300B, 320B, 400B, 420, 430, 470, 480, 500B, 530, 570, 580, 600B, 630, W3 Industrials

Cockshutt - Rear: CO-OP E2, E3, E4, E5; 20, 30, 40, 50, 540, 550 with stamped steel dish Golden Eagle and Blackhawks

IH / Farmall - Front: 140, 240, 300U, 330, 340, 350U, B-250, B-275, B-414, 354, 364, 384, 404, 2404, 424, 2424, 444, 2444, 460, 504, 544, 560, 606, 656, 660, 664, 666, 686, 706, 756, 766, 786, 806, 826, 856, 886, 966, 986, 1026, 1066, 1086, 1206, 1256, 1456, 1466, 1468, 1486, 1566, 1568, 1586, 3088, 3288, 3688, Hydro 70, Hydro 86, Hydro 100, Hydro 186; LH Rear: A, B, BN, Super A, 100, 130, 140; LH and RH Rear Utility only: 240, 300, B-250, B-275, 330, 340, 350, 354, 364, 384, 404, 2404, 424, B414, B424, 444, 3444, 454, 460, 464, 484, 574, 584, 606, 674, 684, 784, 884

John Deere - Rear: A (with hub # A1553R, C391R), B (up to SN: 153375), BW (up to SN: 200999), BWH (up to SN: 200999), D, G (up to SN: 20277), H, MT, 40, 420, 430, 435, 440, 820 (3 cyl), 830 (3 cyl), 1010, 1020, 1520, 1530, 2010, 2020, 2240, 2440, 300 IND, 302 IND, 400 IND; Front: some 820 (3 cyl), 1020, 1520, 1530, 2020, 2030, 2240, 2440, 2510, 2520, 2630, 2640, 3010, 3020, 4000, 4010, 4020, 4030, 4040, 4050, 4230, 4240, 4320, 4430, 4440, 4450, 4455, 4520, 4250, 4055, 4620, 4630, 4640, 4840, 5010, 5020, 6030, 210C Loader

Massey Ferguson - Front: 135, 150, 165, 175, 180, 230, 235, 240, 245, 255, 265, 275, 285, 298, 375, 383, 390, 393, 398, 399, 698, 699, 1080, 1085, 1100, 1105, 1130, 1150, 1155, 2640, 2775, 2805, 3060, 3070, 3090, 3630, 3650, 3140, IND: 203, 205, 2135, 2200, 3165, 4500, 6500, MF20, MF30, MF31, MF40, MF20C, MF30B, MF40B, MF30D

Massey Harris - Rear: Pony, Pacer, Mustang, 20, 22, 30, 33, 44, 44-6, 44 Special, 81, 82, 101 Jr, 102 Jr, 101 Sr, 102 Sr, 333, 444; MM: Rear: R, U, Z, ZA, ZB, JET Star, Jet Star 2, Jet Star 3, 335, 445, Big MO 400, U302; Front: GB, GTB, GBI, G-1000, G-1050, G-1350

Oliver - Front: 77, Super 77, 770, 880, Super 88, 1550, 1555, 1600, 1650, 1655, 1750, 1755, 1800, 1850, 1855, 1900, 1950T, 1955, 2050, 2150, 2255, 2-62, 2-78, 2-70, 2-85, 2-88, 2-105, 2-110, 2-135, 2-150, 2-155; Rear with stamped steel centers: Super 55, 550, 60, 66, Super 66, 660, 70, 77, Super 77, 770, 88, Super 88, 880, 1550, 1555, 1600, 1650, 1655, 2-70, 2-85

Specs

• 9/16" x 18 UNF thread
• 1 1/8" long thread
• 7/8" hex head

Notes

• Check dimensions even if listed to fit the tractor.
• In most cases these fit stamped steel center dishes.
• Can be used as a front bolt on some applications.

Replaces / Cross Reference

• Allis Chalmers: 225191, 251815
• Avery: AT400
• Case: 030739HT
• Cockshutt: FX07
• International Harvester: 51485D
• John Deere: JD16R, JD21, JD17 (Serviceable, hex head is larger), AA4173R, AT11920, T21544, T23252
• Massey: 15597A, MP1584, 518611M91, 519278M91
• MM: 10A7573
• Oliver: 1H706A
