Allis Chalmers B Tractor Parts

Allis-Chalmers B Tractor Parts

About the Allis-Chalmers B

Allis-Chalmers designed the Model B for smaller farms that needed an affordable, useful tractor without the size of a full-scale machine. Introduced in 1937, the B was light and narrow, with an arched front axle and high clearance that made it useful around one-row crops, truck farms, and nurseries.

The Model B was also notable for being sold with pneumatic tires rather than an optional steel-wheel setup. Production continued through 1957.

Serial Number Reference

Serial number locations: The tractor serial number is stamped on top of the transmission case, next to the shift lever. The engine serial number is on the rear left-hand side of the engine, between the carburetor and fuel filter.

The table below uses one beginning tractor serial number for each Model B year:

1937-1943
Model B year Beginning serial number
1937 1
1938 97
1939 11,800
1940 33,502
1941 49,721
1942 56,782
1943 64,501
1944-1950
Model B year Beginning serial number
1944 65,502
1945 70,210
1946 72,265
1947 73,370
1948 80,556
1949 92,295
1950 102,393
1951-1957
Model B year Beginning serial number
1951 114,527
1952 118,674
1953 122,310
1954 124,201
1955 124,711
1956 126,497
1957 127,186

Total production: 120,783 Model B tractors.

The final Model B serial number was 127,461.

Allis-Chalmers B Paint Reference

For restoration planning, the Allis-Chalmers B is listed in the Allis-Chalmers tractor paint guide with the original paint references below.

Allis-Chalmers B paint reference by production period
Production period Metal Wheels Disc Chassis Trim
1929 through 1960 Persian Orange 1 Persian Orange 1, Black Black, Galvanized, Persian Orange 1 Persian Orange 1 Persian Orange 1

Paint placement can vary by production year, series, and equipment configuration.

Filter By

Sort By:

Display Type:
Filters
  • Allis-Chalmers PTO Over-Running Clutch, mechanical tractor part with mounting component and removal tool.

    PTO Over-Running Clutch

    Allis-Chalmers
    $70.75
    MI-138D
    PTO over-running clutch - MI-138D for the listed tractor brands.Tractors up to 75 horsepower.Part Number: MI-138DFitsAllis ChalmersAveryCaseCockshuttFordIH / FarmallJohn DeereMassey FergusonMassey...
    Add to Cart
  • Allis-Chalmers 3 Rib 6.50 x 16 Tire, black rubber agricultural tractor tire with three rib tread design.

    3 Rib 6.50 x 16 Tire

    Allis-Chalmers
    $129.50
    WH-049D
    3 rib 6.50 x 16 tire with triple rib 6 ply construction.Fitment is listed for multiple tractor brands and cross references to whs049.Part Number: WH-049DFitsAllis ChalmersAveryCaseCockshuttFordIH /...
    Add to Cart
  • Allis-Chalmers Slip Fit Coupler for tractors, cylindrical metal part with holes for U-joint attachment.

    Slip Fit Coupler for Tractor Steering Shaft, AB-380D

    Allis-Chalmers
    $109.75
    AB-380D
    Slip fit coupler for tractor steering shafts when a U-joint is needed. Original style part. Use this coupler where the steering shaft requires a universal joint connection.Part number:...
    Add to Cart
  • Allis-Chalmers Tire 6.00 x 16 Triple Rib 4 Ply, black rubber tractor tire with a triple rib tread pattern for Allis-Chalmers equipment.

    Tire 6.00 x 16 Triple Rib 4 Ply for Allis-Chalmers

    Allis-Chalmers
    $119.75
    WH-048D
    Tire only, 6.00 x 16" triple rib 4 ply. Fitment is listed for Allis-Chalmers and several other tractor brands.Part Number: WH-048DFitsAllis ChalmersAveryCaseCockshuttFordIH / FarmallJohn DeereMassey...
    Add to Cart
  • Allis-Chalmers Radiator Shutter Crank for Allis Chalmers B, C, CA, IB tractor, orange metal with handle and mounting end.

    Radiator Shutter Crank for Allis Chalmers B, C, CA, IB

    Allis-Chalmers
    $36.50
    KI1099
    Radiator shutter crank handle for listed Allis Chalmers tractors and AC power units.Part Number: KI1099FitsAllis Chalmers: B, C, CA, IB; serviceable for WC, WF, WD, WD45AC Power Unit: W201, W226
    Add to Cart
  • A round clutch disc with four beige friction pads evenly spaced around its circumference, used for Allis-Chalmers farm tractors, model 70214320.

    Allis-Chalmers 8-1/2" 4 Pad Clutch Disc B, C, CA - 70214320

    Allis-Chalmers
    $115.00
    70214320
    Allis-Chalmers 8 1/2" clutch disc with 4 pads, 1 1/8" hub, and 10 spline.Part Number: 70214320FitsAllis-Chalmers BAllis-Chalmers CAllis-Chalmers CASpecs8 1/2" clutch disc4 pad1 1/8" hub10 spline
    Add to Cart
  • Allis-Chalmers B IB C CA Hood Strap 70211443, black metal tractor hood strap with mounting hardware.

    Allis-Chalmers B IB C CA Hood Strap 70211443

    Allis-Chalmers
    $29.00
    70211443
    Hood strap for Allis-Chalmers B, IB, C, and CA models with starter.Overall length is 38" and 2 mounting bolts are included.Part Number: 70211443FitsAllis Chalmers BAllis Chalmers IBAllis Chalmers...
    Add to Cart
  • Allis-Chalmers Battery Cable 24-inch Non-Insulated AB-403D, with metal ends and braided wire construction.

    Battery Cable 24" Non-Insulated AB-403D

    Allis-Chalmers
    $24.75
    AB-403D
    Battery Cable24" non-insulated 2 gauge ground cable with heavy-duty straight terminals and a 7/16" eyelet opening.FitsAllis Chalmers - variousCase - variousCockshutt - variousFord -...
    Add to Cart
  • Allis-Chalmers Allis Chalmers B C CA IB 8-1/2" Clutch Kit New Spring Loaded Disc Pilot Bearing, image of clutch components including disc, pressure plate, and bearings.

    Allis Chalmers B C CA IB 8-1/2" Clutch Kit New Spring Loaded Disc Pilot Bearing

    Allis-Chalmers
    $449.00
    AC-346DP
    New clutch kit for Allis Chalmers B, C, CA, and IB models. Diameter should be measured before ordering.Includes an 8-1/2" pressure plate, 8-1/2" 10 spline spring loaded clutch disc, throw-out...
    Add to Cart
  • Allis-Chalmers B, C, CA Hood for Hand Start Models, orange metal tractor hood with multiple ventilation holes for engine cooling.

    Allis-Chalmers B, C, CA Hood for Hand Start Models

    Allis-Chalmers
    $409.00
    Ki1035
    Part Number: Ki1035FitsAllis-Chalmers BAllis-Chalmers CAllis-Chalmers CANotesHand startNo lightsIncludes hole for temperature gaugeUSA madeReplaces / Cross Reference21092770210927
    Add to Cart
  • Allis-Chalmers Voltage Regulator Conversion Kit for Allis-Chalmers, black electrical wiring with a grounding clip and a brown plastic component.

    Voltage Regulator Conversion Kit for Allis-Chalmers

    Allis-Chalmers
    $54.75
    AB-188D
    Voltage regulator conversion kit for selected tractors and generators. Use with AB-153D voltage regulator when replacing Delco Remy cutouts listed below.Part Number: AB-188DFitsAllis Chalmers - B, C,...
    Add to Cart
  • Allis-Chalmers Allis Chalmers B C CA IB 8-1/2" Clutch Kit New Solid Disc Pilot Bushing, image of clutch components including clutch disc, pilot bushing, and pressure plate for agricultural tractor.

    Allis Chalmers B C CA IB 8-1/2" Clutch Kit New Solid Disc Pilot Bushing

    Allis-Chalmers
    $439.00
    AC-346SDB
    New clutch kit for Allis Chalmers B, C, CA, and IB models. Diameter should be measured before ordering.Includes an 8-1/2" pressure plate, 8-1/2" 10 spline solid clutch disc, throw-out bearing, and...
    Add to Cart
  • Allis-Chalmers Battery Cable 10-1/2 inch Insulated AB-407D, with metal clamps and black insulated wire for connecting battery terminals.

    Battery Cable 10-1/2" Insulated AB-407D

    Allis-Chalmers
    $17.00
    AB-407D
    Battery Cable 10-1/2" InsulatedHeavy-duty insulated battery cable with straight terminals. This 10-1/2" cable is 2 gauge with a 3/8" eyelet opening.FitsAllis...
    Add to Cart
  • Allis-Chalmers Piston Ring Set 4-Cylinder - Allis Chalmers B Waukesha

    Piston Ring Set 4-Cylinder - Allis-Chalmers B

    Allis-Chalmers
    $105.50
    AB-2166D
    Piston ring set for select 4-cylinder engines with 3-1/4" bore. Verify old rings before ordering, and do not order by tractor model only.Part Number: AB-2166DFitsAllis Chalmers - B (Early w/ Waukesha...
    Add to Cart
  • Allis-Chalmers Piston Ring Set 4-Cylinder - AB-2086D

    Piston Ring Set 4-Cylinder - Allis-Chalmers B C CA

    Allis-Chalmers
    $125.75
    AB-2086D
    Piston ring set for select 4-cylinder engines with 3-7/16" bore. Measure old rings before ordering, and rings can not be returned if opened.Part Number: AB-2086DFitsAllis Chalmers - B, C, CA, IB, RC...
    Add to Cart
  • Allis-Chalmers Rear Rim 8 x 24 - 4 Loops, metal tractor rim for heavy-duty agricultural use.

    Rear Rim 8 x 24 - 4 Loops

    Allis-Chalmers
    $259.75
    WH-001D
    Part Number: WH-001DRear Rim 8 x 24 - 4 LoopsRear rim 8" x 24" with 4 loops. Check the fitment and notes carefully, including bolt and valve stem details.FitsAllis Chalmers - B, C, IB (modification...
    Add to Cart
  • A 9-inch pressure plate clutch for Allis-Chalmers farm tractors, designed for several models including B, IB, C, CA, D10, D12, D14, and WF. The clutch assembly is metallic with multiple attachment points and levers for installation.

    9" Pressure Plate Clutch for Allis-Chalmers B, IB, C, CA, D10, D12, D14, WF

    Allis-Chalmers
    $261.00
    70228926
    9" pressure plate clutch for Allis-Chalmers B, IB, C, CA, D10, D12, D14, and WF.Part Number: 70228926FitsAllis-Chalmers BAllis-Chalmers IBAllis-Chalmers CAllis-Chalmers CAAllis-Chalmers D10 (UP to...
    Add to Cart
  • Allis-Chalmers B C CA Clutch Rod KI1041, a long gray metal clutch linkage rod with a slightly bent end, used for agricultural tractor repair.

    Allis Chalmers B C CA Clutch Rod KI1041

    Allis-Chalmers
    $29.00
    KI1041
    Clutch rod for Allis Chalmers B, C, and CA.Part Number: KI1041FitsAllis Chalmers BAllis Chalmers CAllis Chalmers CASpecs1/2" OD28" longOrdering NotesCheck mounting location, dimensions and tractor...
