Allis Chalmers D14 Tractor Parts

About the Allis-Chalmers D14

The D14 opened the Allis-Chalmers D Series in 1957 as a new compact tractor for row-crop and general farm work. Its 149-cubic-inch four-cylinder engine was available for gasoline or LP gas, and the four-speed transmission could be paired with a transfer case for more gear choices. The D14 was equipped with the Power Director hand clutch, which gave the operator live PTO control without stopping the tractor.

Built through 1960, the D14 sits between the older CA and WD-era tractors and the D15 that followed it. The serial number table below can help identify the tractor's year.

Serial Number Reference

Serial number locations: The tractor serial number is stamped at the left front end of the torque tube. The engine serial number is on the rear left-hand side of the engine, behind the carburetor.

The table below shows the beginning tractor serial number for each Model D14 year:



1957-1958
Model D14 year Beginning serial number
1957 1,001
1958 9,400
1959-1959
Model D14 year Beginning serial number
1959 14,900
1960-1960
Model D14 year Beginning serial number
1960 21,800

Total production: 23,050 Model D14 tractors.

Allis-Chalmers D14 Paint Reference

For restoration planning, the Allis-Chalmers D14 is listed in the Allis-Chalmers tractor paint guide with the original paint references below.

Allis-Chalmers D14 paint reference by production period
Production period Metal Wheels Disc Chassis Trim
1929 through 1960 Persian Orange 1 Persian Orange 1 Persian Orange 1, Aluminum Persian Orange 1 Persian Orange 1, Aluminum grille

Paint placement can vary by production year, series, and equipment configuration.

Filter By

Sort By:

Display Type:
Filters
  • Allis-Chalmers Allis Chalmers Fuel Gauge Screw Set 70918548

    Allis Chalmers Fuel Gauge Screw Set

    Allis-Chalmers
    $13.00
    70918548
    Part Number: 70918548Allis Chalmers Fuel Gauge Screw SetFuel gauge screw set for select Allis Chalmers tractors. This set includes 4 screws and replaces 70918548.FitsAllis Chalmers D10Allis Chalmers...
    Add to Cart
  • Allis-Chalmers Delco Rotor Button AB-520D, a metallic electrical component with a rounded rotor button attached to a gold-colored arm, mounted on a black base.

    Delco Rotor Button

    Allis-Chalmers
    $4.00
    AB-520D
    Part Number: AB-520DProduct OverviewDelco rotor button for applications with a Delco clip held cap.FitsAllis Chalmers: B, IB, C, CA, G, RC, WC, WD, WD45, WF, D10, D12, D14, D15, D17, D19Avery: A, BF,...
    Add to Cart
  • Allis-Chalmers Allis Chalmers Hydraulic Lever Brake Release Knob

    Allis-Chalmers Hydraulic Lever Brake Release Knob

    Allis-Chalmers
    $5.75
    K52
    Part Number: K52Allis-Chalmers Hydraulic Lever Brake Release KnobHydraulic lever and brake release knob with a 1-1/4" diameter and 3/8"-24 thread.FitsVarious models.SpecsDiameter: 1-1/4"Thread:...
    Add to Cart
  • Allis-Chalmers Universal 12 Volt Resistor

    Universal 12 Volt Resistor

    Allis-Chalmers
    $9.75
    AB-366D
    Universal 12 volt resistor, 2-terminal style, reduces voltage with 4 ohms of resistance.Part Number: AB-366DFitsAllis Chalmers - variousCase - variousCockshutt - variousFord - variousInternational -...
    Add to Cart
  • Allis-Chalmers Universal 2 Position Push Pull Switch, electrical control switch with metal and plastic components and rotating mechanism for machinery.

    Universal 2 Position Push Pull Switch

    Allis-Chalmers
    $13.50
    DJS398
    Universal 2 position push pull switch for agricultural and light industrial equipment. For ignition switch applications, it can be used only on battery ignition systems.Switch is a 10amp switch with...
    Add to Cart
  • Allis-Chalmers 12 Volt Bulb for Allis-Chalmers and More, clear glass automotive light bulb with metal base and filament inside.

    12 Volt Bulb for Allis-Chalmers and More

    Allis-Chalmers
    $3.00
    AB-345D
    12 volt bulb for listed tractors and equipment, including Allis-Chalmers, Case, Ford, International, John Deere, Massey Ferguson, Massey Harris, Minneapolis Moline, and Oliver.Part Number:...
    Add to Cart
  • Allis-Chalmers Fan Belt fits Allis Chalmers B IB C CA D10 D12 D14 70209656

    Allis-Chalmers Fan Belt B IB C CA D10 D12 D14 70209656

    Allis-Chalmers
    $15.75
    AB-009D
    Fan belt for Allis-Chalmers tractors with generators, including the listed B, IB, C, CA, D10, D12, and D14 applications.Cross-reference details and belt size are shown below.Part Number:...
    Add to Cart
  • Allis-Chalmers Pin, Control Rod Adjuster Allis Chalmers - 70235812

    Pin, Control Rod Adjuster for Allis-Chalmers 70235812

    Allis-Chalmers
    $18.00
    70235812
    Pin, Control Rod Adjuster for Allis-Chalmers tractors and power units.Used for governor, choke, throttle control and as hydraulic hand control depending on tractor model.Part Number:...
    Add to Cart
  • Allis-Chalmers "O" Ring Fits Aluminum Seal Retainer for PTO Seal Allis Chalmers 70923583 1009659M1

    Allis-Chalmers PTO Seal Aluminum Retainer O-Ring

    Allis-Chalmers
    $4.00
    70923583
    Allis-Chalmers PTO seal aluminum retainer O-ring. New part for the applications listed below.Part Number: 70923583FitsAllis Chalmers - D14, D15, D17, D19, 170, 175, 180, 185, 190, 190XT, 200, 6000...
    Add to Cart
  • Allis-Chalmers Allis Chalmers Choke Rod Knob

    Allis-Chalmers Choke Rod Knob K13

    Allis-Chalmers
    $5.50
    K13
    Allis-Chalmers choke rod knob. New part, SKU K13.Use on D-Series tractors using a choke lever rod.Part Number: K13FitsAllis-Chalmers D-Series using choke lever rodSpecsThread: 1/4" - 20Diameter: 1"
    Add to Cart
  • Allis-Chalmers Thermostat Housing Gasket Allis Chalmers D10 D12 D14 D15 70228125 228125

    Allis Chalmers D10 D12 D14 D15 Thermostat Housing Gasket

    Allis-Chalmers
    $5.75
    70228125
    Part Number: 70228125Product OverviewThermostat housing gasket for the Allis Chalmers models listed below.FitsAllis Chalmers D10Allis Chalmers D12Allis Chalmers D14Allis Chalmers D15Replaces / Cross...
    Add to Cart
  • Allis-Chalmers Allis Chalmers Front Spindle Snap Ring 227827 70227827

    Allis Chalmers Front Spindle Snap Ring

    Allis-Chalmers
    $8.50
    70227827
    Allis Chalmers front spindle snap ring for select tractors and Gleaner combines.Part Number: 70227827FitsAllis Chalmers D14Allis Chalmers D15Allis Chalmers D17Allis Chalmers D19Allis Chalmers...
    Add to Cart
  • Allis-Chalmers Pushrod (sold individually) Allis Chalmers D10, D12, D14, D15

    Pushrod (sold individually) for Allis Chalmers D10, D12, D14, D15

    Allis-Chalmers
    $27.75
    AC-2410D
    Pushrod sold individually for the listed Allis Chalmers applications. Condition: New.Part Number: AC-2410DFitsAllis Chalmers - D10, D12, D14, D15Industrial - 500, 510, 512, 514, 521, 610, 612, 614,...
    Add to Cart
  • Allis-Chalmers Wheel Bearing Sleeve & Seal Kit - Allis Chalmers D10, D12, D14, D15, D17, D19, 160, 170, 175, 180, 185,190, 190XT - 70235120

    Wheel Bearing Sleeve & Seal Kit for Allis Chalmers D10, D12, D14, D15, D17, D19, 160, 170, 175, 180, 185, 190, 190XT

    Allis-Chalmers
    $16.75
    70235120
    Wheel Bearing Sleeve & Seal Kit for Allis Chalmers tractors.Part Number: 70235120FitsAllis Chalmers D10Allis Chalmers D12Allis Chalmers D14Allis Chalmers D15Allis Chalmers D17Allis Chalmers D19Allis...
    Add to Cart
  • Allis-Chalmers Universal Alternator Mounting Bracket Kit

    Universal Alternator Mounting Bracket Kit

    Allis-Chalmers
    $44.75
    AB-404D
    Universal alternator mounting bracket kit for switching from a generator to an alternator. May have to be drilled or modified for your application.Part Number: AB-404DFitsAllis...
    Add to Cart
  • Allis-Chalmers Orange Steering Wheel Spinner Knob WSV125OR

    Orange Steering Wheel Spinner Knob

    Allis-Chalmers
    $13.50
    WSV125OR
    Weather-resistant orange steering wheel spinner knob with a sealed ball bearing. Includes a vinyl-coated aluminum knob and 2 brackets for regular and deep spoked wheels.Part Number: WSV125ORFitsAllis...
    Add to Cart
  • Allis-Chalmers Oil Pressure Gauge Copper Line Kit

    Oil Pressure Gauge Copper Line Kit

    Allis-Chalmers
    $29.75
    AB-523D
    Oil pressure gauge copper line kit for the applications listed below. Includes 6 FT of 1/8" copper line and the fittings listed in the kit contents.Part Number: AB-523DFitsAllis...
    Add to Cart
  • Allis-Chalmers Governor Cover Gasket Allis Chalmers B C IB CA D10 D12 D14 D15 70233213, 233213, 70277271, 277271

    Allis-Chalmers Governor Cover Gasket B C IB CA D10 D12 D14 D15

    Allis-Chalmers
    $5.50
    70233213
    Part Number: 70233213Governor Cover GasketGovernor cover gasket for Allis-Chalmers tractors. Fits the models listed below and replaces the referenced part numbers.FitsAllis-Chalmers BAllis-Chalmers...
    Add to Cart
