Allis Chalmers D14 Tractor Parts

About the Allis-Chalmers D14

The D14 opened the Allis-Chalmers D Series in 1957 as a new compact tractor for row-crop and general farm work. Its 149-cubic-inch four-cylinder engine was available for gasoline or LP gas, and the four-speed transmission could be paired with a transfer case for more gear choices. The D14 was equipped with the Power Director hand clutch, which gave the operator live PTO control without stopping the tractor.

Built through 1960, the D14 sits between the older CA and WD-era tractors and the D15 that followed it. The serial number table below can help identify the tractor's year.

Serial Number Reference

Serial number locations: The tractor serial number is stamped at the left front end of the torque tube. The engine serial number is on the rear left-hand side of the engine, behind the carburetor.

The table below shows the beginning tractor serial number for each Model D14 year:



1957-1958
Model D14 year Beginning serial number
1957 1,001
1958 9,400
1959-1959
Model D14 year Beginning serial number
1959 14,900
1960-1960
Model D14 year Beginning serial number
1960 21,800

Total production: 23,050 Model D14 tractors.

Allis-Chalmers D14 Paint Reference

For restoration planning, the Allis-Chalmers D14 is listed in the Allis-Chalmers tractor paint guide with the original paint references below.

Allis-Chalmers D14 paint reference by production period
Production period Metal Wheels Disc Chassis Trim
1929 through 1960 Persian Orange 1 Persian Orange 1 Persian Orange 1, Aluminum Persian Orange 1 Persian Orange 1, Aluminum grille

Paint placement can vary by production year, series, and equipment configuration.

Sort By:

Display Type:
Filters
  • Allis-Chalmers Viton Needle Float Valve Allis Chalmers Marvel Schebler B C CA D14 D15 G IB RC WC WD WF 70244912

    Viton Needle Float Valve Allis Chalmers Marvel Schebler

    Allis-Chalmers
    $8.00
    AB-230D
    Viton needle float valve for Marvel Schebler carburetors.Viton needle and seat helps stop carb flooding. The orifice measures .070" diameter and the thread is 3/8"-27.Part Number: AB-230DFitsAllis...
  • Allis-Chalmers 4.25 X 16 Front Wheel 5 Hole

    4.25 x 16 Front Wheel 5 Hole for Allis-Chalmers, Cockshutt, Massey Harris

    Allis-Chalmers
    $199.75
    AC-009D
    4.25 x 16 front wheel, 5 hole with listed applications below.Not For tubeless applications. Not recommended for tractors with loaders.Part Number: AC-009DFitsAllis Chalmers: D17, D15, D14 (Early w/ 5...
  • Allis-Chalmers 7/8 inch Snap-In Hole Plug, Nickel Plated, 9563K46, image showing front and back views of the nickel-plated metal hole plug with a serrated interior for secure fit.

    Allis-Chalmers 7/8" Snap-In Hole Plug, Nickel Plated - 9563K46

    Allis-Chalmers
    $1.50
    9563K46
    OverviewNickel plated 7/8" snap-in hole plug for Allis-Chalmers D Series tractors and cigarette lighter openings. Part Number: 9563K46.FitsAllis-Chalmers D Series tractorsCigarette lighter...
  • A metallic flexible choke cable with a round black knob at one end, labeled 'CHOKE,' designed for Allis-Chalmers farm tractors.

    Universal Choke Cable 64"

    Allis-Chalmers
    $19.75
    AC-17033019
    Universal Choke Cable with 64" metal sheathed cable length.Part Number: AC-17033019FitsAllis Chalmers - variousCase - variousCockshutt - variousFord - variousIH / Farmall - Hydro 70, Hydro 86, 300,...
  • Allis-Chalmers Valve Grind Head Gasket Set, engine gasket kit with various gaskets including head gasket, valve seal, and other engine seals for Allis Chalmers D10, D12, D14, D15, H3.

    Allis-Chalmers Valve Grind Head Gasket Set AC-1658D

    Allis-Chalmers
    $49.75
    AC-1658D
    Allis-Chalmers Valve Grind Head Gasket SetPart Number: AC-1658DThis valve grind head gasket set is listed for the Allis-Chalmers tractor and crawler applications below.FitsAllis Chalmers: D10, D12,...
  • Close-up product photo of a black 12-volt, 3-post saddle-mount starter solenoid for an Allis-Chalmers farm tractor. It has two large copper threaded terminals, a smaller control terminal, and metal mounting tabs; labels read “12V” and “733 102.”

    Starter Solenoid 3 Post Saddle Mount 12 Volt

    Allis-Chalmers
    $31.25
    DR1467
    3 post saddle mount starter solenoid for 12 volt systems only. Fits multiple Allis-Chalmers, Case, Cockshutt, International, John Deere, Massey Ferguson, Minneapolis Moline, Oliver, and White...
  • Allis-Chalmers I&T Shop Service Manual, front cover with tractor illustration and descriptive text.

    Allis Chalmers I&T Shop Service Manual

    Allis-Chalmers
    $41.75
    AC-201M
    Allis Chalmers I&T Shop Service ManualAuthentic tractor manual with information for repairs, restoration, specifications, torques, exploded views, and photos. Offers useful shortcuts that may save...
  • One-quart can of Northern Fuel Tank Liner, a gas tank sealer for Allis-Chalmers farm tractors. The can has a blue-and-white label with yellow lettering and a silver metal lid.

    Gas Tank Sealer - 1 Quart Can

    Allis-Chalmers
    $69.99
    ACR2043
    Gas tank sealer in a 1 quart can.Part Number: ACR2043FitsAllis-Chalmers - VariousCase - VariousCockshutt - VariousFord - VariousInternational - VariousJohn Deere - VariousMassey Ferguson -...
  • A brass bushing for Allis-Chalmers farm tractors, specifically the Front Governor Shaft Bushing for models B, C, CA, D10, D12, D14, D15.

    Allis-Chalmers Front Governor Shaft Bushing B C CA D10 D12 D14 D15

    Allis-Chalmers
    $14.75
    AC-3739D
    Front Governor Shaft Bushing for Allis-Chalmers tractors and combines.Part Number: AC-3739DFitsAll the following gas and LP tractors: B, C, CA, D10, D12, D14, D15, D272, IB, RCAllis Chalmers Combines...
  • Allis-Chalmers Delco Distributor Cap Spring Clip With Longer Bracket, automotive ignition distributor part with metal clip, bracket, and screw for engine ignition system repair.

    Delco Distributor Cap Spring Clip With Longer Bracket

    Allis-Chalmers
    $15.00
    AB-488LD
    Part Number: AB-488LDProduct OverviewDistributor cap spring clip with a 1" long bracket, one screw, and two washers. Longer bracket than the bracket in ABC488S.FitsAllis Chalmers: B, IB, C, CA, G,...
  • A set of spark plug wires designed for Allis-Chalmers farm tractors, specifically models D10, D12, D14, D15, and D17.

    Allis Chalmers D10 D12 D14 D15 D17 Spark Plug Wire Set

    Allis-Chalmers
    $33.25
    DJS1005
    Original-style spark plug wire set for Allis Chalmers D10, D12, D14, D15, and D17 tractors.Made and assembled in the USA to original length and style with original style boots.Part Number:...
  • Allis-Chalmers Zenith Carburetor Float  - AB-190D

    Zenith Carburetor Float

    Allis-Chalmers
    $16.75
    AB-190D
    Zenith carburetor float for listed applications. Verify your carburetor manufacturer number before ordering.Part Number: AB-190DFitsAllis Chalmers: B, IB, C, CA, WF, RC w/ zenith 9492 or 9507, WC,...
  • A black gasket designed for Allis-Chalmers farm tractors, not for automobiles, suitable for brands like Allis Chalmers, International, John Deere, Massey Harris, and Minneapolis Moline.

    Gasket for Allis Chalmers, International, John Deere, Massey Harris, Minneapolis Moline

    Allis-Chalmers
    $4.00
    AB-3352D
    Gasket for select Allis-Chalmers, International, John Deere, Massey Harris, and Minneapolis Moline applications.Part Number: AB-3352DFitsAllis Chalmers - B, C, CA, D14, D17, U, WC, WD, WF (Auxiliary...
  • Allis-Chalmers 1/2 inch Snap-In Hole Plug, Nickel Plated, with one view showing the plug's interior and the other showing the smooth exterior surface.

    Allis-Chalmers 1/2" Snap-In Hole Plug, Nickel Plated

    Allis-Chalmers
    $1.00
    9563K43
    Part Number: 9563K43Product Overview1/2 inch snap-in hole plug with a nickel plated finish for Allis-Chalmers D Series tractors. Intended for belt pulley rod or knob holes.FitsAllis-Chalmers D Series...
  • A close-up image of a gold-colored metal bushing, identified as a governor gear bushing for Allis-Chalmers farm tractors, specifically models B, C, CA, D10, D12, D14, D15.

    Allis-Chalmers Governor Gear Bushing B C CA D10 D12 D14 D15

    Allis-Chalmers
    $19.75
    AC-3733D
    Governor Gear Bushing for Allis-Chalmers tractors and combines.Part Number: AC-3733DFitsAll gas and LP tractors: B, C, CA, IB, RC, D10, D12, D14, D15, D272Allis Chalmers Combines - 60, 60A, 60H, 66,...
  • Two black sleeve-sealing O-rings for Allis-Chalmers D10, D12, D14, D15, H3, and I40 farm tractors, overlapping on a white background.

    Allis-Chalmers Sleeve Sealing O Rings for D10, D12, D14, D15, H3, I40

    Allis-Chalmers
    $8.25
    AC-2109D
    Allis-Chalmers Sleeve Sealing O Rings for 1 cylinder applications.Use with the model and serial details listed below. Replacement for 227563 and 70227563.Part Number: AC-2109DFitsD10D12D14D15 — up to...
  • Black, curved upper radiator hose for an Allis-Chalmers D14 farm tractor, part number 70227889.

    Allis Chalmers D14 Upper Radiator Hose | 70227889

    Allis-Chalmers
    $17.50
    70227889
    Upper radiator hose for Allis Chalmers D14 tractors. Listed as replacement number 70227889 with short number 227889.Part Number: 70227889FitsAllis Chalmers D14Replaces / Cross...
  • Gray metal step for Allis-Chalmers D10, D12, D14, and D15 farm tractors, with a textured foot pad connected by an angled support to a flat mounting plate.

    Allis Chalmers D10 D12 D14 D15 Step

    Allis-Chalmers
    $98.75
    DJS1172D
    Aftermarket step for Allis Chalmers D10, D12, D14, and D15 tractors. It attaches to the existing holes on the platform.Part Number: DJS1172DFitsAllis Chalmers - D10, D12, D14, D15NotesSleek black...
