Allis Chalmers D15 Tractor Parts

About the Allis-Chalmers D15

The D15 replaced the D14 in 1960 and carried the compact D Series design into the 1960s. Early D15 tractors used a four-cylinder engine available in gasoline, LP gas, or diesel versions, with more power and an eight-speed transmission option.

There are two main versions to keep in mind: Series I was built from 1960 through 1962, and Series II from 1963 through 1968. Series II tractors received larger gas and LP engines, a dry air cleaner, headlights moved to the rear fenders, and updated hood decals. These changes are why the model year and serial number should be checked before ordering a D15 part.

Serial Number Reference

Serial number locations: On Series I tractors, the tractor serial number is stamped at the left front end of the torque housing. The gasoline engine serial number is on the rear left-hand side behind the carburetor, and the diesel engine serial number is on the top left-hand side of the engine block. On Series II tractors, the tractor serial number is stamped into the flange where the engine and transmission meet on the left side; gasoline engine numbers are at the rear left-hand side near the carburetor, and diesel numbers are on the top left-hand side of the cylinder block.

The table below shows the beginning tractor serial number for each Model D15 year and series:



1960-1962
Model D15 year Beginning serial number
1960 - Series I 1,001
1961 - Series I 1,900
1962 - Series I 6,470
1963-1965
Model D15 year Beginning serial number
1963 - Series II 13,001
1964 - Series II 16,928
1965 - Series II 19,681
1966-1968
Model D15 year Beginning serial number
1966 - Series II 21,375
1967 - Series II 23,734
1968 - Series II 25,127

Total production: 7,169 Model D15 tractors: 6,212 gas/LP and 957 diesel.

Allis-Chalmers D15 Paint Reference

For restoration planning, the Allis-Chalmers D15 is listed in the Allis-Chalmers tractor paint guide with the original paint references below.

Allis-Chalmers D15 paint reference by production period
Production period Metal Wheels Disc Chassis Trim
1961 through 1977 Persian Orange 2 Cream, Persian Orange 2 Cream, Aluminum Persian Orange 2 Cream grille

Paint placement can vary by production year, series, and equipment configuration.

Sort By:

Display Type:
Filters
  • Allis-Chalmers Ignition Switch 4 Position Key Switch

    4 Position Ignition Switch with 2 Keys

    Allis-Chalmers
    $19.75
    AB-400D
    4-position ignition switch for AG and light industrial equipment.Includes 2 keys.Part Number: AB-400DFitsAllis ChalmersAveryCaseCockshuttDavid BrownFordIH / FarmallJohn DeereMassey FergusonMassey...
  • Allis-Chalmers Allis Chalmers Throttle Quadrant, Governor Control BUSHING 70222447

    Allis Chalmers Steering Shaft Bushing Governor Control Bushing

    Allis-Chalmers
    $19.75
    AC-225D
    Allis Chalmers steering shaft bushing / governor control bushing.Used as lower steering shaft support bushing on D19.Part Number: AC-225DFitsAllis Chalmers D14Allis Chalmers D15Allis Chalmers D17...
  • Allis-Chalmers Allis Chalmers Black Steering Wheel ED40 D10 D12 D14 D15 D17 D19 D21

    Allis Chalmers Black Steering Wheel

    Allis-Chalmers
    $57.50
    AC-134D
    Black steering wheel for listed Allis-Chalmers tractors and combines. Like original and made with all new material.Part Number: AC-134DFitsAllis Chalmers - ED40, D10, D12, D14 (sn 19001 and up), D15,...
  • Allis-Chalmers Chrome Fuel Cap for Allis Chalmers, Case, Ford, JD, Massey, representing a shiny, round metal fuel cap with a textured edge.

    Chrome Fuel Cap for Allis Chalmers, Case, Ford, JD, Massey

    Allis-Chalmers
    $13.00
    AB-003D
    Chrome fuel cap with gasket and vented design for the listed tractor applications.Part Number: AB-003DFitsAllis Chalmers: D10, D12, D14, D15, D17, D19, 170, 175, 180, 185, I-40, I-400, I-60, I-600;...
  • Allis-Chalmers 4-3/4 Smooth Glass Lens w/Guide Name

    4-3/4" Smooth Glass Lens with Guide Name

    Allis-Chalmers
    $15.50
    AB-388D
    4-3/4" smooth glass lens with a raised guide logo and raised part number cross reference abc388.Part Number: AB-388DFitsAllis Chalmers: B, IB, C, CA, D10, D12, D14, D15 (up to SN 9001), WC, WD, WD45,...
  • Allis-Chalmers Thermostat 160 Degrees for Allis-Chalmers and More, gold-colored thermostatic valve with a conical top and circular base.

    Thermostat 160 Degrees for Allis-Chalmers and More

    Allis-Chalmers
    $39.75
    IH-913D
    Thermostat 160 degrees with a 2.600" length and 2.510" flange diameter.Fits the listed tractor applications below.Part Number: IH-913DFitsAllis Chalmers: B (Engine SN: 126210 & up when equipped with...
  • A black tension spring for an Allis-Chalmers tractor, with a tightly coiled section, a short curved hook at the left end, and a long straight extension ending in a larger hook at the right. Product 70228219.

    Allis Chalmers Hydraulic / Throttle Control Lever Spring 70228219

    Allis-Chalmers
    $19.95
    70228219
    Allis Chalmers hydraulic / throttle control lever spring for D14, D15, D17, and D19.Part Number: 70228219FitsD14D15D17D19Replaces / Cross Reference70228219NotesUsed on hydraulic and throttle levers.
  • Close-up of a dark metal Allis-Chalmers farm tractor clutch throw-out bearing, a circular component with a wide outer ring and open center, on a white background.

    Clutch Throw Out Bearing (IH Torque Amplifier Release Bearing)

    Allis-Chalmers
    $22.00
    AB-496D
    Clutch throw out bearing, also listed as an IH torque amplifier release bearing. Includes size details and cross references.Part Number: AB-496DFitsAllis Chalmers - 190XT, B, C, CA (W/ 9" Clutch),...
  • Allis-Chalmers INSTRUMENT PANEL GAUGE TRIM Allis Chalmers D14 D15 D17 D19

    Instrument Panel Gauge Trim for Allis-Chalmers D14 D15 D17 D19

    Allis-Chalmers
    $39.75
    DJS353
    Instrument panel gauge trim for Allis-Chalmers D14, D15, D17, and D19. USA made and finished in brushed stainless steel.Part Number: DJS353FitsD14D15D17D19Replaces / Cross...
  • A black Flame Thrower Coil with a flame logo in the center, labeled as Pertronix Flame Thrower Coil 40,000 Volts 12V, designed for Allis-Chalmers farm tractors.

    Pertronix Flame Thrower Coil 40,000 Volts 12V

    Pertronix
    $56.50
    ACR3205
    Pertronix Flame Thrower Coil, 40,000 volts, 12V, oil filled, high performance.Heavy duty mount in vertical position. Use with electronic ignition kit.Part Number: ACR3205Specs40,000 volts12VNotesOil...
  • Allis-Chalmers Headlight Assembly 12 Volt  FD-193D

    Headlight Assembly 12 Volt for Allis-Chalmers and Ford

    Allis-Chalmers
    $54.50
    FD-193D
    12 volt headlight assembly for select Allis-Chalmers and Ford models. Mounts to the side of the grille, not the fender. OD is 5-3/4" with a 1/2"-13 stud. Part Number: FD-193D Fits Allis Chalmers:...
  • A set of eight metallic screw hardware pieces arranged in two rows, designed for Allis-Chalmers D series farm tractors.

    Allis Chalmers D10, D12, D14, D15, D17, D19, D21 Seat Screw Hardware Kit

    Allis-Chalmers
    $4.75
    70916081
    Allis Chalmers D10, D12, D14, D15, D17, D19, D21Seat Screw Hardware KitPart Number: 70916081FitsD10D12D14D15D17D19D21Replaces / Cross Reference70916081Specs8 piece set of seat cushion screws1/4-
  • Flat, dark Allis-Chalmers water pump mounting gasket with three bolt holes and a large central opening, shown on a white background.

    Allis Chalmers Water Pump Mounting Gasket B C CA IB D10 D12 D14 D15

    Allis-Chalmers
    $5.75
    70234382
    Water pump mounting gasket for Allis Chalmers tractors listed below.Condition: NewPart Number: 70234382FitsAllis Chalmers BAllis Chalmers CAllis Chalmers CAAllis Chalmers IBAllis Chalmers D10Allis...
  • Black Allis-Chalmers tractor control knob with a rounded dome top and ridged band around its middle, shown against a white background. Fits D10, D12, D14, D15, and D17 farm tractors.

    OEM Choke Knob, Hydraulic Knob, Fuel Shut Off for Allis-Chalmers D10, D12, D14, D15, D17

    Allis-Chalmers
    $10.00
    70234686
    OEM Choke Knob, Hydraulic Knob, Fuel Shut Off for select Allis-Chalmers tractors.Part Number: 70234686FitsAllis Chalmers - D10 (as a choke knob), D12 (as choke knob), D14, D15 (as hydraulic spool...
  • A circular black metal thrust washer for Allis-Chalmers farm tractors, specifically a spindle thrust washer.

    Spindle Thrust Washer for Allis Chalmers Tractors

    Allis-Chalmers
    $7.50
    70218762
    Spindle thrust washer for select Allis Chalmers tractors.Part Number: 70218762FitsWDWD45WD45 DieselD10D12D14D15D19175180185190200D17 (early models with 5 bolt hub)170 (late models)6060 (with 96"...
  • Allis-Chalmers farm tractor oil pump repair kit arranged on a white background, with metal parts, springs, and several shaped gaskets.

    Allis Chalmers Oil Pump Repair Kit

    Allis-Chalmers
    $149.75
    AC-3420D
    Allis Chalmers oil pump repair kit for listed tractors, forklifts, combines, power units, and a loader.Kit includes a rotor blade set, rotor blade springs, rotor blade shaft, and gaskets. Some...
  • A small clear incandescent bulb with a brass-colored bayonet base, shown horizontally on a white background. Allis-Chalmers Power Director light bulb for farm tractors.

    Allis-Chalmers Power Director Light Bulb

    Allis-Chalmers
    $3.00
    9527T602
    Bulb for the Power Director Light Assembly on select Allis-Chalmers tractors.Part Number: 9527T602FitsAllis Chalmers D14Allis Chalmers D15Allis Chalmers D17Allis Chalmers D19Allis Chalmers D21Allis...
  • Allis-Chalmers Cast Rocker Arm Support Stand for D10, D12, D14, D15 models, black metal tractor engine component.

    Cast Rocker Arm Support Stand Allis Chalmers D10 D12 D14 D15

    Allis-Chalmers
    $37.75
    AC-1196D
    Cast rocker arm support stand for Allis Chalmers gas and LP models. Sold individually, 4 used per tractor.Part Number: AC-1196DFitsAllis Chalmers Gas / LP - D10, D12, D14, D15, I40, I60, I400, I600,...
