Allis Chalmers WD45 Tractor Parts

About the Allis-Chalmers WD45

The WD45 replaced the WD in 1953 and gave Allis-Chalmers a stronger four-plow row-crop tractor without losing the WD's live PTO and Snap-Coupler layout. Its 226-cubic-inch gas, tractor-fuel, or LP engine made it noticeably more powerful than the WD.

The WD45 was the first Allis-Chalmers tractor offered with power steering, which became available in 1956. A six-cylinder diesel was added after Allis-Chalmers acquired Buda, and the WD45 remained in production through 1957.

Serial Number Reference

Serial number locations: The tractor serial number is stamped at the left brake cover or the left rear of the axle housing. The gasoline engine serial number is on the left-hand side of the engine near the carburetor; diesel engine numbers are on the left-hand side of the diesel engine.

The table below shows the beginning tractor serial number for each Model WD45 year:



1953-1954
Model WD45 year Beginning serial number
1953 146,607
1954 160,386
1955-1956
Model WD45 year Beginning serial number
1955 190,993
1956 217,992
1957-1957
Model WD45 year Beginning serial number
1957 230,295

Total production: 90,382 Model WD45 tractors (83,536 gasoline and 6,509 diesel; the LP/tractor-fuel total is unknown).

Allis-Chalmers WD45 Paint Reference

For restoration planning, the Allis-Chalmers WD45 is listed in the Allis-Chalmers tractor paint guide with the original paint references below.

Allis-Chalmers WD45 paint reference by production period
Production period Metal Wheels Disc Chassis Trim
1929 through 1960 Persian Orange 1 Persian Orange 1 Persian Orange 1, Aluminum Persian Orange 1 Persian Orange 1

Paint placement can vary by production year, series, and equipment configuration.

Filter By

Sort By:

Display Type:
Filters
  • Allis-Chalmers 6-inch Battery Cable, heavy-duty braided silver cable with metal terminal end for automotive battery connections.

    6" Battery Cable

    Allis-Chalmers
    $15.75
    AB-401D
    6" ground battery cable, non-insulated, 2 gauge, with heavy duty straight terminals.Part Number: AB-401DFitsAllis Chalmers - D14 (Ground strap), D17 (Ground Strap on Diesel up to SN: 38963 and All...
    Add to Cart
  • Black 19-inch cushion pad for an Allis-Chalmers farm tractor seat, with a smooth vinyl surface, raised padded edges, and a contoured center.

    Black Tractor Seat Pad Cushion 19"

    Allis-Chalmers
    $39.50
    YF30BLK
    This black tractor seat pad cushion is for tractors with a round pan seat. It fits a 19" to 21" seat pan side to side and uses a drawstring attachment.Part Number: YF30BLKFitsAllis Chalmers - B, C,...
    Add to Cart
  • Allis-Chalmers Tie Rod Boot - JD-736D, black rubber automotive part with a wide base and a hollow cylindrical opening.

    Tie Rod Boot JD-736D

    Allis-Chalmers
    $4.95
    JD-736D
    Tie Rod Boot JD-736DNew tie rod boot with the dimensions listed below. Review the fitment and replacement numbers carefully before ordering.FitsListed fitment includes:Allis...
    Add to Cart
  • Round dark metal belt pulley and PTO shaft seal for Allis-Chalmers B-125, WC, WF, WD, WD45, and WD45D farm tractors, shown from the front.

    Belt Pulley / PTO Shaft Seal for Allis Chalmers B-125 WC WF WD WD45 WD45D

    Allis-Chalmers
    $18.75
    70208417
    Belt pulley / PTO shaft seal for listed Allis-Chalmers applications.Part Number: 70208417FitsAllis Chalmers - B-125 Power Unit, WC, WF, WD, WD45, WD45 Diesel (Belt Pulley Shaft Seal)Allis Chalmers -...
    Add to Cart
  • Allis-Chalmers 12-Volt Bullet Style Tail Light, black tail light with red wire, for Allis Chalmers B, C, CA, G, WD, WD45, D10, D12, D14 tractor models.

    12-Volt Bullet Style Tail Light for Allis Chalmers B C CA G WD WD45 D10 D12 D14

    Allis-Chalmers
    $44.75
    OL-070D
    12-volt bullet style tail light for Allis-Chalmers tractors. Painted black piggy lamp.Part Number: OL-070DFitsAllis Chalmers: B, C, CA, G, WD, WD45, D10, D12, D14Minneapolis Moline: 4 Star, 5 Star,...
    Add to Cart
  • A set of ten yellowish-orange shim pieces for Allis-Chalmers farm tractor main bearing caps, with various hole and shape sizes.

    Allis-Chalmers Main Bearing Cap Shim Kit

    Allis-Chalmers
    $29.75
    AC-3504D
    Allis-Chalmers Main Bearing Cap Shim Kit for WC, WD, WD45, and WF models. Includes 12 shims for center, rear, and front main bearing caps.Part Number: AC-3504DFitsAllis Chalmers - WC, WD, WF, WD45...
    Add to Cart
  • A manual for aftermarket Fairbanks Morse FM-J magneto parts, specifically types FM-J4A and FM-J4A-2 for Allis-Chalmers farm tractors. The cover is beige with black text and an illustration of the magneto.

    Fairbanks Morse FM-J Magneto Parts & Instruction Manual

    Aftermarket
    $23.25
    MANFMJ
    Fairbanks Morse FM-J Magneto Parts & Instruction Manual for Allis Chalmers B, IB, C, CA, RC, WC, WF, WD, and WD45, plus various other models.Part Number: MANFMJFitsAllis Chalmers BAllis Chalmers...
    Add to Cart
  • Allis-Chalmers Spark Plug Wiring Set with Straight Boots, automotive ignition wires with black silicone insulation, and six black rubber spark plug boots, plus six brass terminal connectors, designed for reliable engine performance.

    Spark Plug Wiring Set with Straight Boots

    Allis-Chalmers
    $19.75
    AC-228D
    Part Number: AC-228DSpark Plug Wiring Set with Straight BootsSpark Plug Wiring Set w/ Straight Boots for applications using straight boots. See the fitment list below for the models supplied.FitsAC...
    Add to Cart
  • Allis-Chalmers Standard Connecting Rod Bearing for Allis-Chalmers Diesel, silver metal bearing with a circular shape and a cutout section

    Standard Connecting Rod Bearing for Allis-Chalmers Diesel

    Allis-Chalmers
    $18.75
    AB-2495D
    Standard connecting rod bearing for Allis-Chalmers diesel applications and other listed models. Preserve the supplied application details carefully.Part Number: AB-2495DFitsAC Combines - Gleaner: F...
    Add to Cart
  • Allis-Chalmers Allis Chalmers WD45 Fuel Line Steel

    Allis Chalmers WD45 Fuel Line Steel

    Allis-Chalmers
    $44.75
    AC-1866D
    Steel fuel line for Allis Chalmers WD45 (Gas).Includes 24" overall length and 1/4" tube O.D. with 1/4" 45° inverted flare nuts.Part Number: AC-1866DFitsAllis Chalmers: WD45 (Gas)Replaces / Cross...
    Add to Cart
  • A black felt-like seal, a gray metal washer, and a flat, circular metal retainer ring, all components of an Allis-Chalmers Front Hub Oil Seal Kit with washer and retainer.

    Allis-Chalmers Front Hub Oil Seal Kit With Washer And Retainer

    Allis-Chalmers
    $14.75
    FWSKAC2
    Front hub oil seal kit with washer and retainer for select Allis-Chalmers tractors. New condition.Part Number: FWSKAC2FitsAllis Chalmers D10 (w/ 5 bolt front hub SN: 3501 & up and High Clear up to...
    Add to Cart
  • Allis-Chalmers Headlight Lens w / Guide Name (4-3/4")

    Headlight Lens w/ Guide Name 4-3/4"

    Allis-Chalmers
    $15.75
    IH-352D
    Part Number: IH-352DHeadlight Lens w/ Guide NameThis 4-3/4" headlight lens has a "GUIDE" marking near the bottom of the lens and a dimpled outer surface. It is interchangeable with the original...
    Add to Cart
  • A Pertronix Electronic Ignition Conversion Kit for Allis-Chalmers farm tractors, including a wiring harness, a black ignition module, a metal mounting plate, a rubber grommet, and two red and silver connectors.

    Pertronix Electronic Ignition Conversion Kit 12V Positive Ground for Allis-Chalmers B IB C CA D10 D12 D14 D15 D17 G WC WD WD45 WF

    Pertronix
    $211.00
    ACR5102
    Pertronix Ignitor electronic ignition conversion kit for Delco 4-cylinder applications with 12V positive ground. Replaces points and condenser with a breakerless solid-state ignition system that fits...
    Add to Cart
  • Allis-Chalmers Viton Needle Float Valve for Marvel Schebler carburetors - C701V

    Viton Needle Float Valve for Marvel Schebler Carburetors

    Allis-Chalmers
    $8.00
    C701V
    Viton needle float valve for Marvel Schebler carburetors.Viton needle and seat helps stop carb flooding. 3/8-27 thread, .080 orifice size.Part Number: C701VFitsAllis Chalmers: WD45, D15, D17, D19,...
    Add to Cart
  • A set of spark plug wire leads for Allis-Chalmers WD and WD45 farm tractors, featuring black wires with brass and metal connectors.

    Allis Chalmers WD WD45 Spark Plug Wire Set

    Allis-Chalmers
    $33.50
    DJS1016
    Original-style spark plug wire set for Allis Chalmers WD and WD45 tractors.Made and assembled in the USA to original length and style with original style boots.Part Number: DJS1016FitsAllis Chalmers...
    Add to Cart
  • Allis-Chalmers REAR TIRE INNER TUBE VALVE - AB-384D

    Rear Tire Inner Tube Valve for Tractor Tubes with External Threads

    Allis-Chalmers
    $11.75
    AB-384D
    Rear tire inner tube valve for tractor tubes with external threads.Old style air/water valve, sold individually.Part Number: AB-384DFitsAllis ChalmersAveryCaseCockshuttFordIH / FarmallJohn...
    Add to Cart
  • Allis-Chalmers Universal 3 Position Push/Pull Light Switch - JD-631D, electrical switch with metal and plastic components and a black toggle handle.

    Universal 3 Position Push/Pull Light Switch - JD-631D

    Allis-Chalmers
    $14.75
    JD-631D
    Universal 3 Position Push/Pull Light Switch - JD-631DThis universal 3 position push/pull light switch is rated for 15 amps and uses 5 terminals. It includes the black plastic knob.FitsAllis...
    Add to Cart
  • Coiled main wiring harness for Allis-Chalmers WD and WD45 farm tractors, with black braided protective sleeving, visible red, white, and green wires, and metal terminal ends.

    Allis-Chalmers WD / WD45 Main Wiring Harness | ACR4766

    Allis-Chalmers
    $93.00
    ACR4766
    Part Number: ACR4766Allis-Chalmers WD / WD45 Main Wiring HarnessMain wiring harness for Allis-Chalmers WD and WD45.FitsAllis-Chalmers WDAllis-Chalmers WD45Replaces / Cross Reference70208337208337
    Add to Cart
