Allis Chalmers 170 Tractor Parts

About the Allis-Chalmers 170

The Allis-Chalmers 170 was one of the larger tractors in the company's 1960s line. Introduced in 1967 as the One-Seventy, it used a four-cylinder engine, live PTO, hydraulic power assist, and an eight-speed transmission with two-speed power shift.

Early Allis-Chalmers literature calls it the One-Seventy, while later tractors use the numeric 170 marking. The model was available with gasoline or diesel power and was built through 1973, so the tractor year and serial number are useful when matching parts.

Serial Number Reference

Serial number locations: The tractor serial number is on the left front side of the torque housing. The gasoline engine serial number is at the rear left side of the engine block behind the carburetor. The diesel engine serial number is on the top right side of the cylinder block.

The table below shows the beginning tractor serial number for each Model 170 year:



1967-1969
Model 170 year Beginning serial number
1967 1,005
1968 2,721
1969 5,374
1970-1971
Model 170 year Beginning serial number
1970 6,369
1971 6,988
1972-1973
Model 170 year Beginning serial number
1972 7,797
1973 8,821

Total production: 9,303 Model 170 tractors; fuel-type production totals were not available.

Allis-Chalmers 170 Paint Reference

For restoration planning, the Allis-Chalmers 170 is listed in the Allis-Chalmers tractor paint guide with the original paint references below.

Allis-Chalmers 170 paint reference by production period
Production period Metal Wheels Disc Chassis Trim
1961 through 1977 Persian Orange 2 Cream Cream, Aluminum Persian Orange 2 Persian Orange 2

Paint placement can vary by production year, series, and equipment configuration.

Filter By

Sort By:

Display Type:
Filters
  • Allis-Chalmers 170 175 D17 Clutch Kit, image of clutch components including pressure plate, clutch disc, and release bearing.

    Allis Chalmers 170 175 D17 Clutch Kit

    Allis-Chalmers
    $558.00
    D242572KIT1
    Part Number: D242572KIT1Allis Chalmers 170, 175, D17 Series IV Clutch KitNew clutch kit includes an 11" pressure plate, woven clutch disc, throw-out bearing, and pilot bearing.FitsAllis Chalmers...
    Add to Cart
  • Allis-Chalmers D17 170 175 Delco Starter, industrial starter motor for tractor engines with mounting flange and gear pinion.

    Allis-Chalmers D17 170 175 Delco Starter

    Allis-Chalmers
    $430.00
    79004823
    Allis-Chalmers - D17 (Prior to Series 4 Gas), D17 (Series 4 Gas), 170 (Gas), 175 (Gas)Re-manufactured Delco - 12 Volt - 9 Teeth - CWPart Number: 79004823FitsAllis-Chalmers Tractor - D17 (PRIOR TO...
    Add to Cart
  • Allis-Chalmers Allis Chalmers 170 175 Diesel Head Gasket Set, engine gasket components laid out.

    Allis Chalmers 170 175 Diesel Head Gasket Set

    Allis-Chalmers
    $47.50
    70255432
    Allis Chalmers - 170 Diesel, 175 DieselHead Gasket SetPart Number: 70255432FitsAllis Chalmers - 170 Diesel, 175 DieselMassey Ferguson - 165, 168, 174, 174C, 175, 175 US BUILT, 178, 184, 185, 188,...
    Add to Cart
  • Woodruff Key for Steering Wheel, Crankshaft Gear and Pulley, metallic key with half-moon shape used in automotive and machinery applications.

    Woodruff Key for Steering Wheel, Crankshaft Gear and Pulley

    DJS Tractor Parts
    $2.00
    70251052
    1/4" x 7/8" Woodruff Key Use this Woodruff Key for steering wheel, crankshaft gear, and pulley applications on the listed tractors and equipment. Part Number: 70251052Fits Steering wheel shaft key:...
    Add to Cart
  • Allis-Chalmers D19 170 175 Pressure Plate, 11 inch no hub, with metal components and mounting holes, used in agricultural machinery.

    Allis Chalmers D19 170 175 Pressure Plate 11 in No Hub 70241253

    Allis-Chalmers
    $435.00
    70241253
    Pressure Plate for Allis Chalmers D19, 170, and 175 tractors.11", no hub, 9 spring.Replaces 70241253.Part Number: 70241253FitsD19170175Specs11"No hub9 springReplaces / Cross Reference70241253
    Add to Cart
  • Allis-Chalmers Chrome Fuel Cap for Allis Chalmers, Case, Ford, JD, Massey, representing a shiny, round metal fuel cap with a textured edge.

    Chrome Fuel Cap for Allis Chalmers, Case, Ford, JD, Massey

    Allis-Chalmers
    $13.00
    AB-003D
    Chrome fuel cap with gasket and vented design for the listed tractor applications.Part Number: AB-003DFitsAllis Chalmers: D10, D12, D14, D15, D17, D19, 170, 175, 180, 185, I-40, I-400, I-60, I-600;...
    Add to Cart
  • Allis-Chalmers 170 175 Diesel Water Pump with Pulley, engine cooling water pump for diesel tractors.

    Allis-Chalmers 170 175 Diesel Water Pump with Pulley

    Allis-Chalmers
    $77.00
    79003714M
    New water pump with pulley for select Allis-Chalmers tractors and related applications. Gasket included.FitsAllis Chalmers Tractor - 170Allis Chalmers Tractor - 175Allis Chalmers Construction &...
    Add to Cart
  • Allis-Chalmers 170 175 Diesel Delco Starter, automotive starter motor for vintage tractor models.

    Allis-Chalmers 170 175 Diesel Delco Starter

    Allis-Chalmers
    $585.00
    79004848
    Remanufactured 12-volt Delco starter for Allis-Chalmers 170 and 175 diesel tractors.FitsAllis Chalmers 170 DieselAllis Chalmers 175 DieselReplaces / Cross Reference79004848249694Delco 1107859Delco...
    Add to Cart
  • Allis-Chalmers D17, 170, 175 Main Bearing Set, 0.020 Undersize, engine parts, main bearings, piston bearings, industrial machinery

    Allis Chalmers D17 170 175 Main Bearing Set 0.020 Undersize

    Allis-Chalmers
    $119.75
    AC-2784D
    Main bearing set for Allis Chalmers D17, 170, and 175.Undersize 0.020" main journal, 2.980", sold as a set.Part Number: AC-2784DFitsAllis Chalmers D17Allis Chalmers 170Allis Chalmers 175SpecsMain...
    Add to Cart
  • Allis-Chalmers 170 175 Pistons Sleeves and Rings Kit, image showing four pistons, four cylinders, piston rings, sleeves, and additional engine components.

    Allis Chalmers 170 175 Pistons Sleeves and Rings Kit

    Allis-Chalmers
    $720.00
    R-CK7458
    Kit for Allis Chalmers 170 and 175.Includes cupped pistons, sleeves, O-rings, piston rings, pins, and clips.4-1/8" over bore.Part Number: R-CK7458FitsAllis Chalmers 170Allis Chalmers 175Replaces /...
    Add to Cart
  • Aftermarket 12V Distributor Hot Coil 55000 Volts Internally Resisted, black electrical coil component with mounting brackets and terminal connectors.

    12V Distributor Hot Coil 55000 Volts Internally Resisted

    Aftermarket
    $59.75
    AB-6158D
    12V distributor hot coil with 55,000 volts and internally resisted design. No external resistor required.Works with or without electronic ignition system.Part Number: AB-6158DFitsAllis Chalmers - B,...
    Add to Cart
  • Allis-Chalmers Muffler for Allis Chalmers 170 Diesel and 175 Diesel, black exhaust muffler with a vertical pipe on top.

    Muffler for Allis Chalmers 170 Diesel, 175 Diesel

    Allis-Chalmers
    $117.00
    ACR1567
    Allis Chalmers - 170 Diesel, 175 DieselMuffler - Vertical ExhaustPart Number: ACR1567Replaces / Cross Reference70250049SpecsInlet I.D. - 2 3/8"Outlet O.D. - 2 1/4"Overall Length - 34"Shell Diameter -...
    Add to Cart
  • Allis-Chalmers 4.25 x 16 6 Lug Front Wheel for Allis Chalmers, cream-colored tractor wheel with lug holes for installation.

    4.25 x 16 6 Lug Front Wheel for Allis Chalmers

    Allis-Chalmers
    $159.75
    WH-6137D
    4.25" x 16" 6 lug front wheel for select Allis Chalmers tractors.Part Number: WH-6137DFitsAllis Chalmers: D15 (SN 9001 & up), D17 (SN 75001 & up), D19, ED40, 160, 170, 175, 180, 185, 190, 190XT,...
    Add to Cart
  • Allis-Chalmers Brake Lock Lever Spring, black coiled spring for Allis Chalmers D10 D12 D14 D15 D17 170 175 tractor models.

    Brake Lock Lever Spring for Allis Chalmers D10 D12 D14 D15 D17 170 175

    Allis-Chalmers
    $9.75
    70230364
    Brake lock lever spring for select Allis Chalmers tractors and hydraulic remote adjustment rod applications. Part Number: 70230364Fits Allis Chalmers D10 Allis Chalmers D12 Allis Chalmers D14 Allis...
    Add to Cart
  • Allis-Chalmers Timing Gear Cover Gasket, engine timing gear cover gasket for Allis Chalmers D17, WC, WD, WD45, WF, 170, 175 with part number 70233214.

    Timing Gear Cover Gasket Allis Chalmers D17 WC WD WD45 WF 170 175 70233214

    Allis-Chalmers
    $9.75
    70233214
    Timing gear cover gasket for select Allis Chalmers models. Check engine serial details before ordering.0.032" thick with 7 mounting holes and 7/16" mounting hole ID.Part Number: 70233214FitsWD, WD45,...
    Add to Cart
  • Allis-Chalmers NBR Rubber Fuel Sending Unit Gasket, black rubber gasket with four bolt holes for fuel tank sealing.

    NBR Rubber Fuel Sending Unit Gasket

    Allis-Chalmers
    $4.25
    AB-3256RD
    NBR Rubber Fuel Sending Unit Gasket for select Allis Chalmers and other tractor models.Use the application and replacement numbers below to confirm fitment.Part Number: AB-3256RDFitsAllis Chalmers:...
    Add to Cart
  • Allis-Chalmers Power Director Light Lens - Green, close-up of a vibrant green light lens with a ribbed, dome-shaped design on a plain white background.

    Allis Chalmers Power Director Light Lens - Green

    Allis-Chalmers
    $12.25
    70240838-G
    Green Power Director light lens for select Allis Chalmers tractors.Use the part numbers below to confirm your application.Part Number: 70240838-GFitsAllis Chalmers D17, D19, D21, 170, 175, 180, 185,...
