Allis Chalmers D14 Tractor Parts

About the Allis-Chalmers D14

The D14 opened the Allis-Chalmers D Series in 1957 as a new compact tractor for row-crop and general farm work. Its 149-cubic-inch four-cylinder engine was available for gasoline or LP gas, and the four-speed transmission could be paired with a transfer case for more gear choices. The D14 was equipped with the Power Director hand clutch, which gave the operator live PTO control without stopping the tractor.

Built through 1960, the D14 sits between the older CA and WD-era tractors and the D15 that followed it. The serial number table below can help identify the tractor's year.

Serial Number Reference

Serial number locations: The tractor serial number is stamped at the left front end of the torque tube. The engine serial number is on the rear left-hand side of the engine, behind the carburetor.

The table below shows the beginning tractor serial number for each Model D14 year:



1957-1958
Model D14 year Beginning serial number
1957 1,001
1958 9,400
1959-1959
Model D14 year Beginning serial number
1959 14,900
1960-1960
Model D14 year Beginning serial number
1960 21,800

Total production: 23,050 Model D14 tractors.

Allis-Chalmers D14 Paint Reference

For restoration planning, the Allis-Chalmers D14 is listed in the Allis-Chalmers tractor paint guide with the original paint references below.

Allis-Chalmers D14 paint reference by production period
Production period Metal Wheels Disc Chassis Trim
1929 through 1960 Persian Orange 1 Persian Orange 1 Persian Orange 1, Aluminum Persian Orange 1 Persian Orange 1, Aluminum grille

Paint placement can vary by production year, series, and equipment configuration.

Filter By

Sort By:

Display Type:
Filters
  • Allis-Chalmers Oil Pump Body to Cylinder Block Gasket, round gasket with multiple holes for fitting

    Allis-Chalmers Oil Pump Body to Cylinder Block Gasket

    Allis-Chalmers
    $5.00
    70277273
    Oil Pump Body To Cylinder Block Gasket. New gasket for the listed Allis-Chalmers applications.Part Number: 70277273FitsAllis-Chalmers BAllis-Chalmers IBAllis-Chalmers CAllis-Chalmers CAAllis-Chalmers...
    Add to Cart
  • Aftermarket Top Link, industrial mechanical linkage component for heavy machinery or agricultural equipment, shown with a rod and mounting eye

    Top Link, Category 2

    Aftermarket
    $45.75
    FD-346D
    Top Link, Category 2 for tractors using a Cat 2 three-point hitch.Part Number: FD-346DFitsAllis Chalmers: D17, D19, 170, 175, 180, 185, 190, 190XT, 200, 7000; and OTHER MODELS USING CAT 2 THREE POINT...
    Add to Cart
  • Allis-Chalmers Wiring Harness Kit (Tractors with 1 Wire Alternator) Allis Chalmers D14 D15 Series I

    Wiring Harness Kit for Allis Chalmers D14 D15 Series I

    Allis-Chalmers
    $259.50
    DJS1030
    Wiring Harness Kit for tractors with a 1-wire alternator.Part Number: DJS1030FitsAllis Chalmers D14Allis Chalmers D15 Series INotesComplete wiring harness kit.For tractors with a 1-wire alternator.
    Add to Cart
  • Allis-Chalmers 12 Volt Round Red Tail Light Assembly with License Lamp Window, vintage tractor lighting part.

    12 Volt Round Red Tail Light Assembly w/ License Lamp Window

    Allis-Chalmers
    $13.75
    AB-548D
    Part Number: AB-548D12 Volt Round Red Tail Light Assembly w/ License Lamp Window12 volt round red tail light assembly with a license lamp window. For multiple tractor applications listed below...
    Add to Cart
  • Allis-Chalmers Battery Cable 12 inch Insulated AB-415D, a black electrical battery cable with metal terminals on both ends.

    Allis-Chalmers Battery Cable 12" Insulated AB-415D

    Allis-Chalmers
    $17.75
    AB-415D
    Battery Cable 12" InsulatedThis 12" insulated battery cable is a heavy-duty 2 gauge cable with straight terminals. It has a 3/8" eyelet opening and is intended for select tractor applications...
    Add to Cart
  • Allis-Chalmers 3 in. O.D. Raincap Zinc-Plated, industrial rain cap with durable zinc coating and polished metal finish.

    3 in. O.D. Raincap Zinc-Plated

    Allis-Chalmers
    $44.75
    RC-015D
    Part Number: RC-015D3" O.D. Raincap Zinc-PlatedFits straight chrome pipe on listed applications. Zinc-plated with 3" O.D.FitsAllis Chalmers BAllis Chalmers IBAllis Chalmers CAllis Chalmers CAAllis...
    Add to Cart
  • Allis-Chalmers Radiator, Allis Chalmers D14, industrial cooling radiator for farm equipment.

    Radiator - Allis Chalmers D14

    Allis-Chalmers
    $510.00
    ACR3987
    Radiator for Allis Chalmers D14.Part Number: ACR3987FitsAllis Chalmers D14SpecsOverall Height: 21"Overall Width: 17 1/8"Core Depth: 2"5" thick3 Rows of Tubes9 Fins per InchReplaces / Cross...
    Add to Cart
  • Allis-Chalmers 1ST PINION SHAFT GEAR | Allis Chalmers CA D10 D12 D14 D15 | 70228296 70225835

    Allis Chalmers 1st Pinion Shaft Gear CA D10 D12 D14 D15

    Allis-Chalmers
    $133.75
    70228296
    1st pinion shaft gear for Allis Chalmers CA, D10, D12, D14, and D15 tractors.50 teeth.Part Number: 70228296FitsAllis Chalmers CA (13291 & up)Allis Chalmers D10Allis Chalmers D12Allis Chalmers...
    Add to Cart
  • Allis-Chalmers Handle Light Mount 70236328, black metal mounting handle.

    Allis-Chalmers Handle Light Mount 70236328

    Allis-Chalmers
    $50.00
    70236328
    Part Number: 70236328Allis-Chalmers Handle Light MountThis Allis-Chalmers handle light mount is listed for the tractor models below. Made in USA.FitsAllis-Chalmers D10Allis-Chalmers D12Allis-Chalmers...
    Out of stock
  • Allis-Chalmers Collar, Pinion Shaft 2nd & 3rd Gear (8 Tooth) | Allis Chalmers CA D10 D12 D14 D15 | 70228291

    Allis Chalmers Collar, Pinion Shaft 2nd & 3rd Gear (8 Tooth)

    Allis-Chalmers
    $212.50
    70228291
    Collar, Pinion Shaft 2nd & 3rd Gear for Allis-Chalmers CA, D10, D12, D14, and D15 applications.Part Number: 70228291FitsAllis Chalmers CA (SN 13291 and up)Allis Chalmers D10Allis Chalmers D12Allis...
    Add to Cart
  • Allis-Chalmers Raincap 3 in. 3 3/16 in. I.D., a durable metallic rain cap with mounting plate for protection and weather resistance in agricultural machinery.

    Raincap 3 in. 3 3/16 in. I.D.

    Allis-Chalmers
    $16.00
    RC-009D
    Part Number: RC-009DRaincapRaincap with a 3" - 3 3/16" inside diameter.FitsAllis ChalmersCaseCockshuttDavid BrownFordIH / FarmallJohn DeereMassey FergusonOliverSpecs3" - 3 3/16" I.D.
    Add to Cart
  • Allis-Chalmers 2 Gauge Battery Cable 14-1/2" Insulated AB-413D, black electrical battery cable with terminal ends for vehicle battery connections.

    2 Gauge Battery Cable 14-1/2" Insulated AB-413D

    Allis-Chalmers
    $18.75
    AB-413D
    Battery Cable 14-1/2" InsulatedThis 2 gauge insulated battery cable is 14-1/2 inches long and has 90 degree terminal ends with a 3/8" eyelet opening. On some applications, the eyelet hole may have to...
    Add to Cart
  • Allis-Chalmers Front Wheel Clamp Lock Nut for Allis-Chalmers, Avery, Case, Ford, John Deere, Massey Ferguson, showing a metal locking nut with internal gear teeth and a small metal pin.

    Front Wheel Clamp Lock Nut for Allis-Chalmers, Avery, Case, Ford, John Deere, Massey Ferguson

    Allis-Chalmers
    $24.25
    AB-254D
    Front wheel clamp lock nut for Allis-Chalmers and other listed tractor models.Check thread size before ordering. For axle shaft and front wheel applications with 3/4" - 16 NF thread. No re-threading...
    Add to Cart
  • AGCO Allis Chalmers Timing Gear Cover Gasket, black rubber gasket with multiple holes for fitting, part number 70277268.

    Allis Chalmers Timing Gear Cover Gasket | 70277268

    AGCO
    $13.75
    70277268
    Allis Chalmers Timing Gear Cover GasketPart Number: 70277268FitsAllis Chalmers D10Allis Chalmers D12Allis Chalmers D14Allis Chalmers D15Replaces / Cross Reference70277268277268NotesCondition: New.
    Add to Cart
  • Allis-Chalmers Crankshaft for Allis-Chalmers D10 D12 D14 D15 H3, engine crankshaft component for tractor engines.

    Crankshaft for Allis-Chalmers D10 D12 D14 D15 H3

    Allis-Chalmers
    $599.00
    AC-073D
    Crankshaft for Allis-Chalmers D10, D12, D14, D15 gas, H3, and listed forklift models using 138, 149 or 160 cubic inch engines.For bearings see AC-1954D and AC-1952D.Part Number: AC-073DFitsAllis...
    Add to Cart
  • Allis-Chalmers Tire 5.50 x 16 Triple Rib 6 Ply for Allis-Chalmers, black tire with triple rib tread pattern, designed for durable performance on agricultural equipment.

    Tire 5.50 x 16 Triple Rib 6 Ply for Allis-Chalmers

    Allis-Chalmers
    $104.75
    WH-047D
    Triple rib 6 ply tire sized 5.50 x 16. Fitment is listed for Allis-Chalmers and several other tractor brands.Part Number: WH-047DFitsAllis ChalmersAveryCaseCockshuttFordIH / FarmallJohn DeereMassey...
    Add to Cart
  • Allis-Chalmers Lower Generator Bracket B C CA D10 D12 D14, black metal engine part for tractor generator support.

    Allis Chalmers Lower Generator Bracket B C CA D10 D12 D14

    Allis-Chalmers
    $19.50
    AC-1913D
    Lower generator bracket for select Allis Chalmers tractors and the W226 power unit. Made in the USA with a bare finish.Part Number: AC-1913DFitsBCCAD10 up to SN 3500D12 up to SN 3000D14W226 Power...
    Add to Cart
  • Allis-Chalmers Piston Ring Set D10 D12 D14 D15, image of multiple piston rings arranged in rows.

    Allis Chalmers Piston Ring Set D10 D12 D14 D15

    Allis-Chalmers
    $155.00
    70230092
    Allis Chalmers Piston Ring SetPiston ring set for Allis Chalmers 4-cylinder gas engines in the listed tractor models. Fits prior to S/N 9001.Part Number: 70230092FitsAllis Chalmers D10 prior to S/N...
    Add to Cart
