Allis Chalmers WD45 Tractor Parts

About the Allis-Chalmers WD45

The WD45 replaced the WD in 1953 and gave Allis-Chalmers a stronger four-plow row-crop tractor without losing the WD's live PTO and Snap-Coupler layout. Its 226-cubic-inch gas, tractor-fuel, or LP engine made it noticeably more powerful than the WD.

The WD45 was the first Allis-Chalmers tractor offered with power steering, which became available in 1956. A six-cylinder diesel was added after Allis-Chalmers acquired Buda, and the WD45 remained in production through 1957.

Serial Number Reference

Serial number locations: The tractor serial number is stamped at the left brake cover or the left rear of the axle housing. The gasoline engine serial number is on the left-hand side of the engine near the carburetor; diesel engine numbers are on the left-hand side of the diesel engine.

The table below shows the beginning tractor serial number for each Model WD45 year:



1953-1954
Model WD45 year Beginning serial number
1953 146,607
1954 160,386
1955-1956
Model WD45 year Beginning serial number
1955 190,993
1956 217,992
1957-1957
Model WD45 year Beginning serial number
1957 230,295

Total production: 90,382 Model WD45 tractors (83,536 gasoline and 6,509 diesel; the LP/tractor-fuel total is unknown).

Allis-Chalmers WD45 Paint Reference

For restoration planning, the Allis-Chalmers WD45 is listed in the Allis-Chalmers tractor paint guide with the original paint references below.

Allis-Chalmers WD45 paint reference by production period
Production period Metal Wheels Disc Chassis Trim
1929 through 1960 Persian Orange 1 Persian Orange 1 Persian Orange 1, Aluminum Persian Orange 1 Persian Orange 1

Paint placement can vary by production year, series, and equipment configuration.

Filter By

Sort By:

Display Type:
Filters
  • Allis-Chalmers Steering Joints Repair Kit AB-280D, rusty and used steering joint component for agricultural machinery.

    Allis-Chalmers Steering Joints Repair Kit AB-280D

    Allis-Chalmers
    $139.75
    AB-280D
    Allis-Chalmers Steering Joints Repair Kit AB-280DThis steering joints repair kit is listed for Allis-Chalmers WC, WD, WD45, and WD45D models. It includes yokes, pins, and a grease fitting.FitsAllis...
    Add to Cart
  • Allis-Chalmers WD WD45 Hood Strap 70208109, black metal tractor hood support strap.

    Allis-Chalmers WD WD45 Hood Strap 70208109

    Allis-Chalmers
    $36.00
    70208109
    Hood strap for Allis-Chalmers WD and WD45 models.Fuel tank strap, hood strap, radiator strap 70208109 with an overall length of 44-1/2".Part Number: 70208109FitsAllis Chalmers WDAllis Chalmers...
    Add to Cart
  • Allis-Chalmers WD45 Water Bypass Hose, black cylindrical metal pipe with printed serial numbers on surface.

    Allis-Chalmers WD45 Water Bypass Hose

    Allis-Chalmers
    $7.00
    70226316
    Water bypass hose for Allis-Chalmers WD45 early models and W226 power unit applications.Part Number: 70226316FitsAllis Chalmers - Early WD45 (up to Engine Sn# 50788)Power unit: W226 (up to Sn#...
    Add to Cart
  • Illustrative image of assorted dark and silver piston rings arranged in several overlapping stacks. Text on image reads “FOR ILLUSTRATIVE PURPOSES ONLY.” Product: Allis-Chalmers four-cylinder piston ring set for some 170, 175, D17, WC, WD, WD45, and WF farm tractors.

    Allis-Chalmers Piston Ring Set 4-Cylinder SOME 170, 175, D17, WC, WD, WD45, WF

    Allis-Chalmers
    $146.75
    AB-2082D
    Part Number: AB-2082DAllis-Chalmers Piston Ring SetFor select Allis-Chalmers, Case, International, and Massey Harris applications with 4" bore. Includes the listed compression and oil ring dimensions...
    Add to Cart
  • Illustrative assortment of dark and silver piston rings arranged in overlapping groups on a white background. Allis-Chalmers 6-cylinder piston ring set for a WD45 Diesel farm tractor; image is marked “For illustrative purposes only.”

    Piston Ring Set 6-Cylinder for Allis-Chalmers WD45 Diesel

    Allis-Chalmers
    $215.75
    AB-2178D
    Allis-Chalmers WD45 Diesel piston ring set for a 6-cylinder engine.3-1/2" bore, (3) 0.125" compression rings, (1) 0.250" oil ring. Measure old rings before ordering. Rings can NOT be returned if...
    Add to Cart
  • Wire Mini Alternator with Pulley 35 Amp, showing a compact automotive alternator with attached pulley and electrical connector on a brown background.

    1 Wire Mini Alternator with Pulley 35 Amp (Display)

    Allis-Chalmers
    $159.50
    466
    1 wire mini alternator with pulley, 35 amp. Used to convert 6 volt systems to 12 volt systems on negative ground systems only. Preferred for tractors requiring a smaller diameter alternator for...
    Add to Cart
  • Wire Mini Alternator with Pulley 35 Amp, compact metal automotive alternator with pulley and wiring connector, displayed on a plain surface.

    1 Wire Mini Alternator with Pulley 35 Amp (Display)

    Allis-Chalmers
    $159.50
    465
    1 wire mini alternator with pulley, 35 amp. Used to convert 6 volt systems to 12 volt systems on negative ground systems only. Preferred for tractors requiring a smaller diameter alternator for...
    Add to Cart
  • 105 Amp One Wire Alternator with Pulley for 6V to 12V Conversion, shiny metallic alternator with a pulley and an orange display tag attached.

    105 Amp One Wire Alternator with Pulley for 6V to 12V Conversion

    Allis-Chalmers
    $103.75
    464
    105 amp one wire alternator with pulley, used for converting 6 volt to 12 volt systems. Built-in regulator and 1 wire hook up for 12 volt negative ground systems. Part Number: AB-418D Fits Allis...
    Add to Cart
  • 12 Volt Voltage Regulator for Allis-Chalmers WD45, D15, D17 Diesel, used parts display.

    12 Volt Voltage Regulator for Allis-Chalmers WD45 D15 D17 Diesel (Display)

    Allis-Chalmers
    $30.50
    635
    12 volt voltage regulator for select Allis-Chalmers and other tractor applications. This is a 12 V voltage regulator saddle mount. Part Number: ACR6368 Fits Allis Chalmers - [WD45 Diesel, D15...
    Add to Cart
  • 160 Degree Thermostat - Allis Chalmers, Case, Cockshutt, Massey Ferguson, display showing used parts for tractor cooling system.

    160 Degree Thermostat - Allis Chalmers, Case, Cockshutt, Massey Ferguson (Display)

    Allis-Chalmers
    $27.75
    507
    160 degree thermostat for select Allis Chalmers, Case, Cockshutt, Massey Ferguson, and Massey Harris models. Part Number: AB-1898D Fits Allis Chalmers - D10, D12, D14, D15 with 4 bolt housing. WD,...
    Add to Cart
  • 6 Volt Distributor Coil AB-011D, display model of a black ignition coil with electrical connectors on top on a cardboard surface

    6 Volt Distributor Coil AB-011D (Display)

    Allis-Chalmers
    $22.25
    550
    6 Volt Distributor Coil - AB-011D This 6 volt distributor coil is listed as AB-011D and fits listed tractor applications. It includes multiple cross-reference numbers across several brands...
    Add to Cart
  • 6 Volt Voltage Regulator for Allis-Chalmers, black rectangular display unit with electrical terminals on the side, used parts display

    6 Volt Voltage Regulator for Allis-Chalmers (Display)

    Allis-Chalmers
    $34.25
    634
    6 volt external voltage regulator for selected tractors and generators. For positive ground systems with an A-type circuit and 7 to 9 amp output. Part Number: AB-153D Fits Allis Chalmers - B, C, CA,...
    Add to Cart
  • 63 Amp One Wire Alternator with Pulley for 6V to 12V Conversion, automotive electrical part displayed on a cardboard surface.

    63 Amp One Wire Alternator with Pulley for 6V to 12V Conversion (Display)

    Allis-Chalmers
    $103.75
    462
    63 amp one wire alternator with pulley, used for converting 6 volt to 12 volt systems. Built-in regulator and 1 wire hook up for 12 volt negative ground systems. Part Number: AB-418D Fits Allis...
    Add to Cart
  • 7 PSI Radiator Cap for Allis Chalmers, Case, Ford, IH, John Deere, display of radiator cap on a brown background.

    7 PSI Radiator Cap for Allis Chalmers, Case, Ford, IH, John Deere (Display)

    Allis-Chalmers
    $8.50
    531
    7 PSI radiator cap. For listed applications with a 1-inch tall filler neck. Condition: New. Part Number: AB-1396D Fits Allis Chalmers - B (sn 61221 & up), C (sn 18581 and up), CA, G, RC, WC (sn...
    Add to Cart
  • Allis Chalmers Gear Shift Lever Pins, Pair Oversized (Display), two metal pins with different sizes and shapes on a brown background with a white label showing the number 653 and 'Used Parts / Display' text.

    Allis Chalmers Gear Shift Lever Pins, Pair Oversized (Display)

    Allis-Chalmers
    $11.75
    653
    Allis Chalmers gear shift lever pins, pair, oversized. AC-253D is used to tighten up a worn shift lever and must be ground to fit the existing worn lever. Part Number: AC-253D Fits Allis Chalmers...
    Add to Cart
  • Allis Chalmers WD45 Diesel D17 Air Cleaner Cap, display of used tractor air cleaner cap on brown background with barcode label

    Allis Chalmers WD45 Diesel D17 Air Cleaner Cap(Display)

    Allis-Chalmers
    $26.50
    519
    Air cleaner cap for Allis Chalmers WD45 diesel and D17 applications. Includes a 2.275" I.D. inlet base and a 4.94" diameter cap. Part Number: AC-226D Fits Allis Chalmers WD45 Dsl Allis Chalmers D17...
    Add to Cart
  • Allis-Chalmers 12 Volt Chrome Bullet Style Tail Light Assembly, display showing a vintage chrome bullet-shaped tail light with wiring and mounting hardware on a brown background.

    Allis-Chalmers 12 Volt Chrome Bullet Style Tail Light Assembly (Display)

    Allis-Chalmers
    $23.25
    571
    12 volt chrome bullet style tail light assembly for select Allis-Chalmers and John Deere models. It is a 1 wire 12 volt chrome bullet style tail light assembly with a plastic lens. Part Number:...
    Add to Cart
  • Allis-Chalmers 4 PSI Radiator Cap, display showing used part with a metal radiator cap featuring a circular design with the word 'TIGHTEN' and 'REMOVE SLOWLY' embossed around the center.

    Allis-Chalmers 4 PSI Radiator Cap (Display)

    Allis-Chalmers
    $7.75
    538
    Allis-Chalmers 4 PSI radiator cap includes the gasket and is like the original. For 4 PSI pressurized systems with a 1.500" radiator neck ID. Part Number: AB-008D Fits Allis Chalmers: B (sn 61221 &...
    Add to Cart
