Allis Chalmers WD45 Tractor Parts

About the Allis-Chalmers WD45

The WD45 replaced the WD in 1953 and gave Allis-Chalmers a stronger four-plow row-crop tractor without losing the WD's live PTO and Snap-Coupler layout. Its 226-cubic-inch gas, tractor-fuel, or LP engine made it noticeably more powerful than the WD.

The WD45 was the first Allis-Chalmers tractor offered with power steering, which became available in 1956. A six-cylinder diesel was added after Allis-Chalmers acquired Buda, and the WD45 remained in production through 1957.

Serial Number Reference

Serial number locations: The tractor serial number is stamped at the left brake cover or the left rear of the axle housing. The gasoline engine serial number is on the left-hand side of the engine near the carburetor; diesel engine numbers are on the left-hand side of the diesel engine.

The table below shows the beginning tractor serial number for each Model WD45 year:



1953-1954
Model WD45 year Beginning serial number
1953 146,607
1954 160,386
1955-1956
Model WD45 year Beginning serial number
1955 190,993
1956 217,992
1957-1957
Model WD45 year Beginning serial number
1957 230,295

Total production: 90,382 Model WD45 tractors (83,536 gasoline and 6,509 diesel; the LP/tractor-fuel total is unknown).

Allis-Chalmers WD45 Paint Reference

For restoration planning, the Allis-Chalmers WD45 is listed in the Allis-Chalmers tractor paint guide with the original paint references below.

Allis-Chalmers WD45 paint reference by production period
Production period Metal Wheels Disc Chassis Trim
1929 through 1960 Persian Orange 1 Persian Orange 1 Persian Orange 1, Aluminum Persian Orange 1 Persian Orange 1

Paint placement can vary by production year, series, and equipment configuration.

Filter By

Sort By:

Display Type:
Filters
  • A two-position push-pull ignition and light switch for an Allis-Chalmers farm tractor, shown isolated on a white background. It has a rectangular metal housing, exposed electrical terminals on top, and a yellow pull knob on a threaded shaft.

    Universal 2 Position Push Pull Ignition Light Switch

    Allis-Chalmers
    $7.50
    SSW2809
    Universal 2 position push/pull switch for ignition or light use. It is non-fused and includes a plastic knob. Part Number: SSW2809 Fits Allis Chalmers - Various Case - Various Cockshutt -...
    Add to Cart
  • Allis-Chalmers Allis Chalmers Head Gasket Set WC WF WD WD45 D17 170 175

    Allis-Chalmers Head Gasket Set WC WF WD WD45 D17 170 175

    Allis-Chalmers
    $69.75
    AC-291D
    Head gasket set for Allis-Chalmers WC, WF, WD, WD45, D17, 170 Gas/LP, and 175 Gas/LP models.Includes all gaskets needed to replace the cylinder head.Part Number: AC-291DFitsAllis-Chalmers WC (engine...
    Add to Cart
  • Orange and white 19-inch seat cushion pad for an Allis-Chalmers farm tractor, shown on a white background.

    Orange and White Tractor Seat Pad Cushion 19"

    Allis-Chalmers
    $39.50
    YF30WO
    This orange and white tractor seat pad cushion is for tractors with a round pan seat. It fits a 19" to 21" seat pan side to side and uses a drawstring attachment.Part Number: YF30WOFitsAllis Chalmers...
    Add to Cart
  • Allis-Chalmers Front Wheel Bearing Kit AC-1793D, image of metal bearing rings, rollers, a black rubber seal, and a black felt pad arranged on a white background.

    Allis Chalmers Front Wheel Bearing Kit AC-1793D

    Allis-Chalmers
    $65.75
    AC-1793D
    Allis Chalmers Front Wheel Bearing KitPart number: AC-1793DFront wheel bearing kit for Allis Chalmers tractors with a 5 bolt front hub. Sold individually; 2 used per tractor.FitsWC, WD, WD45, RC (5...
    Add to Cart
  • A metallic cylindrical tube with knurled grip at one end and a small hole drilled near the end, designed for Allis-Chalmers farm tractors, product number 70203899.

    Allis-Chalmers Oil Filter Tube Element Stand Pipe 70203899

    Allis-Chalmers
    $19.75
    KI1189
    Allis-Chalmers oil filter tube element stand pipe for the listed Allis-Chalmers and AC Misc. applications.Part Number: KI1189FitsAllis Chalmers - G, B, C, CA, IB, RC, WC, WF, WD, WD45, D10, D12, D14,...
    Add to Cart
  • Pertronix 12-volt electronic ignition conversion kit for Allis-Chalmers farm tractors, shown with a circular ignition module plate, red and black wires, terminal connectors, and black rubber components on a white background.

    Electronic Ignition Conversion Kit 12V for Allis Chalmers B, IB, C, CA, D10, D12, D14, D15, D17, G, WC, WD, WD45, WF

    Pertronix
    $191.50
    ACR3189
    Ignitor Delco fits 4-cylinder applications with 12 volt negative ground. This electronic ignition conversion kit replaces points and condenser with a breakerless solid state system. It fits entirely...
    Add to Cart
  • Allis-Chalmers OEM (AGCO) BRAND Belt Pulley Gasket | Allis Chalmers WD WD45 WC WF | 70202289

    AGCO Belt Pulley Gasket Allis Chalmers WD, WD45, WC, WF 70202289

    Allis-Chalmers
    $25.25
    70202289
    Belt pulley gasket for Allis Chalmers tractors.This AGCO brand cork gasket goes between the frame and transmission torque tube.Part Number: 70202289FitsAllis Chalmers: WD, WD45, WC, WFNotesItem #...
    Add to Cart
  • Allis-Chalmers Oil Pressure Gauge 0-80 PSI, round metal pressure gauge showing normal oil pressure level.

    Allis-Chalmers Oil Pressure Gauge 0-80 PSI AC-262D

    Allis-Chalmers
    $31.75
    AC-262D
    Allis-Chalmers Oil Pressure Gauge 0-80 PSIPart Number: AC-262DThis 0-80 PSI oil pressure gauge is listed for the models below. It has 1/8" male pipe threads.FitsAllis Chalmers: A, D15 (DSL), D17...
    Add to Cart
  • Allis-Chalmers Allis Chalmers Complete Engine Gasket Set WC WF WD WD45 D17 170 175

    Allis Chalmers Complete Engine Gasket Set WC WF WD WD45 D17 170 175

    Allis-Chalmers
    $129.75
    AC-1320D
    Complete engine gasket set for select Allis-Chalmers tractor and industrial applications. Includes all gaskets and crankshaft seals for a major engine overhaul.Part Number: AC-1320DFitsWD, WD45, D17,...
    Add to Cart
  • A dark, curved metal spring for an Allis-Chalmers Snap Coupler bell hook, part number 70226514, shown against a white background.

    Allis-Chalmers Snap Coupler Bell Hook Spring 70226514

    Allis-Chalmers
    $18.75
    70226514
    Allis-Chalmers snap coupler bell hook spring for the listed tractors with quick hitch system.Use the fitment information below to confirm application.Part Number: 70226514FitsAllis-Chalmers...
    Add to Cart
  • A metal clevis pin and R-clip used for Allis-Chalmers farm tractors, specifically for drawbar hanger cradle. The clevis pin is cylindrical with a hole at one end, showing signs of rust and wear. The R-clip is a shiny, curved metal pin that secures the clevis pin in place.

    Allis-Chalmers Clevis Pin & R-Clip for Drawbar Hanger Cradle

    Allis-Chalmers
    $5.75
    70220873
    Clevis Pin & R-Clip for Drawbar Hanger / Draw Bar Cradle. New set for listed Allis-Chalmers applications.Important fitment notes and measurements are preserved below.Part Number:...
    Add to Cart
  • Allis-Chalmers Delco Rotor Button AB-520D, a metallic electrical component with a rounded rotor button attached to a gold-colored arm, mounted on a black base.

    Delco Rotor Button

    Allis-Chalmers
    $4.00
    AB-520D
    Part Number: AB-520DProduct OverviewDelco rotor button for applications with a Delco clip held cap.FitsAllis Chalmers: B, IB, C, CA, G, RC, WC, WD, WD45, WF, D10, D12, D14, D15, D17, D19Avery: A, BF,...
    Add to Cart
  • Close-up of a circular brown-and-black rear axle outboard bull gear seal for Allis-Chalmers D10, D12, D14, D15, WD, and WD45 farm tractors.

    Allis-Chalmers Rear Axle Out Board of Bull Gear Seal for D10, D12, D14, D15, WD, WD45

    Allis-Chalmers
    $16.50
    70218284
    Seal for Rear Axle Out Board of Bull Gear (Axle Hub).Part Number: 70218284FitsAllis-Chalmers D10Allis-Chalmers D12Allis-Chalmers D14Allis-Chalmers D15Allis-Chalmers WDAllis-Chalmers WD45Replaces /...
    Add to Cart
  • Black, round Allis-Chalmers hydraulic lever brake release knob for a farm tractor, shown against a white background.

    Allis-Chalmers Hydraulic Lever Brake Release Knob

    Allis-Chalmers
    $5.75
    K52
    Part Number: K52Allis-Chalmers Hydraulic Lever Brake Release KnobHydraulic lever and brake release knob with a 1-1/4" diameter and 3/8"-24 thread.FitsVarious models.SpecsDiameter: 1-1/4"Thread:...
    Add to Cart
  • Allis-Chalmers universal 12-volt resistor for farm tractors, shown as a white ceramic rectangular component with two copper terminal tabs and a central metal mounting bracket with a round hole.

    Universal 12 Volt Resistor

    Allis-Chalmers
    $9.75
    AB-366D
    Universal 12 volt resistor, 2-terminal style, reduces voltage with 4 ohms of resistance.Part Number: AB-366DFitsAllis Chalmers - variousCase - variousCockshutt - variousFord - variousInternational -...
    Add to Cart
  • A universal 2-position push-pull switch designed for Allis-Chalmers farm tractors, not for automobiles.

    Universal 2 Position Push Pull Switch

    Allis-Chalmers
    $13.50
    DJS398
    Universal 2 position push pull switch for agricultural and light industrial equipment. For ignition switch applications, it can be used only on battery ignition systems.Switch is a 10amp switch with...
    Add to Cart
  • A gasket designed for Allis-Chalmers farm tractors, specifically for the hydraulic pump body to reservoir connection. It is a flat, irregularly shaped piece with multiple holes around its perimeter for fitting and sealing.

    Allis-Chalmers Hydraulic Pump Gasket Body to Reservoir

    Allis-Chalmers
    $9.75
    70222530
    Allis-Chalmers Hydraulic Pump Gasket, Body to ReservoirNew hydraulic pump gasket for the body to reservoir.Part Number: 70222530FitsAllis-Chalmers WDAllis-Chalmers WD45Replaces / Cross...
    Add to Cart
  • Allis-Chalmers Allis Chalmers Seat Pivot Bushing CA WD WD45

    Allis Chalmers Seat Pivot Bushing CA WD WD45

    Allis-Chalmers
    $35.00
    AC-328D
    Allis Chalmers seat pivot bushing for CA, and WD, WD45 applications with a pan seat. One used per tractor.Part Number: AC-328DFitsAllis Chalmers: CA, all with pan seat: WD (sn 127007 and up), WD45,...
    Add to Cart
