Allis Chalmers D14 Tractor Parts

About the Allis-Chalmers D14

The D14 opened the Allis-Chalmers D Series in 1957 as a new compact tractor for row-crop and general farm work. Its 149-cubic-inch four-cylinder engine was available for gasoline or LP gas, and the four-speed transmission could be paired with a transfer case for more gear choices. The D14 was equipped with the Power Director hand clutch, which gave the operator live PTO control without stopping the tractor.

Built through 1960, the D14 sits between the older CA and WD-era tractors and the D15 that followed it. The serial number table below can help identify the tractor's year.

Serial Number Reference

Serial number locations: The tractor serial number is stamped at the left front end of the torque tube. The engine serial number is on the rear left-hand side of the engine, behind the carburetor.

The table below shows the beginning tractor serial number for each Model D14 year:



1957-1958
Model D14 year Beginning serial number
1957 1,001
1958 9,400
1959-1959
Model D14 year Beginning serial number
1959 14,900
1960-1960
Model D14 year Beginning serial number
1960 21,800

Total production: 23,050 Model D14 tractors.

Allis-Chalmers D14 Paint Reference

For restoration planning, the Allis-Chalmers D14 is listed in the Allis-Chalmers tractor paint guide with the original paint references below.

Allis-Chalmers D14 paint reference by production period
Production period Metal Wheels Disc Chassis Trim
1929 through 1960 Persian Orange 1 Persian Orange 1 Persian Orange 1, Aluminum Persian Orange 1 Persian Orange 1, Aluminum grille

Paint placement can vary by production year, series, and equipment configuration.

Filter By

Sort By:

Display Type:
Filters
  • Allis-Chalmers Hydraulic Pump Screen Gasket Allis Chalmers D14 D15 D17 D19 70233249 233249

    Allis Chalmers Hydraulic Pump Screen Gasket for D14 D15 D17 D19

    Allis-Chalmers
    $18.75
    70233249
    Part Number: 70233249Allis Chalmers Hydraulic Pump Screen GasketOEM AGCO brand hydraulic pump screen gasket for the listed Allis Chalmers tractors.FitsAllis Chalmers D14Allis Chalmers D15Allis...
    Add to Cart
  • Allis-Chalmers LOWER WATER PIPE | Allis Chalmers D10 D12 D14 D15

    Allis-Chalmers Lower Water Pipe for D10 D12 D14 D15 | AC-249D

    Allis-Chalmers
    $39.75
    AC-249D
    Lower water pipe for Allis-Chalmers D10, D12, D14, and D15. Fits gas and LP models. SKU AC-249D.Part Number: AC-249DFitsAllis-Chalmers D10Allis-Chalmers D12Allis-Chalmers D14Allis-Chalmers...
    Add to Cart
  • Allis-Chalmers Delco Starter Commutator Brush Band Cover, metallic band with mounting screw for engine starter repair.

    Delco Starter Commutator Brush Band Cover

    Allis-Chalmers
    $19.75
    AB-1203D
    Delco starter commutator (brush) band cover for select Allis-Chalmers and other tractor models.Made in the USA. Comes complete as shown, with screw and nut.Part Number: AB-1203DFitsAllis Chalmers...
    Add to Cart
  • Allis-Chalmers Allis Chalmers Valve Train Kit B C IB RC CA

    Allis Chalmers Valve Train Kit B C IB RC CA

    Allis-Chalmers
    $124.75
    AC-2129D
    Valve train kit for select Allis Chalmers models. Includes the listed replacement parts and usage notes.Part Number: AC-2129DFitsB, C, IB, RC (with engine serial numbers CE161057 and above)CAD10 (up...
    Add to Cart
  • Allis-Chalmers Steering Wheel Spinner, metallic steering wheel knob and mounting hardware on white background.

    Steering Wheel Spinner

    Allis-Chalmers
    $13.50
    ACR3275
    Ball bearing steering wheel spinner made of aluminum.Part Number: ACR3275FitsAllis Chalmers - variousCase - variousCockshutt - variousFord - variousInternational - variousJohn Deere - variousMassey...
    Add to Cart
  • Allis-Chalmers D14 D15 Clutch Inspection Cover Plate 227610, round orange metal cover with two holes, with metal clips attached.

    Allis-Chalmers D14 D15 Clutch Inspection Cover Plate 227610

    Allis-Chalmers
    $19.75
    AC-1507D
    Clutch inspection cover plate for Allis-Chalmers D14 and D15 tractors. Replaces: 227610, 70227610 Note: May vary in color. Primed for convenience. Part Number: AC-1507DFits Allis-Chalmers D14 ...
    Add to Cart
  • Allis-Chalmers 1 Wire Mini Alternator with Pulley 35 Amp 1/2 Pulley

    1 Wire Mini Alternator with Pulley 35 Amp

    Allis-Chalmers
    $199.50
    AB-535D
    1 wire mini alternator with pulley, 35 amp. Used to convert 6 volt systems to 12 volt systems on negative ground systems only. Preferred for tractors requiring a smaller diameter alternator for...
    Add to Cart
  • Allis-Chalmers CRANKSHAFT PULLEY | Allis Chalmers CA D14 D10 D12

    Crankshaft Pulley for Allis Chalmers CA D14 D10 D12

    Allis-Chalmers
    $54.75
    AC-089D
    Part Number: AC-089DAllis Chalmers Crankshaft PulleyFor Allis Chalmers CA, D14, D10 (up to sn 35000), and D12 (up to sn 3000). Serviceable for B, C, and IB, but does not have provisions for hand...
    Add to Cart
  • Allis-Chalmers Light Ring 4-3/4 inch, black circular light ring with mounting hardware for agricultural equipment.

    Light Ring 4-3/4"

    Allis-Chalmers
    $15.75
    IH-353BD
    Light ring 4-3/4" with black finish.Interchangeable with original.Part Number: IH-353BDFitsAllis-Chalmers B, IB, C, CA, D10, D12, D14, D15 (up to sn 9001), WC, WD, WD45AveryCase VA, VAC, VAH (All up...
    Add to Cart
  • Allis-Chalmers Allis Chalmers D Series Hydraulic Position Control Vinyl Decal, close-up image of the decal with detailed text and markings.

    Allis Chalmers D Series Hydraulic Position Control Vinyl Decal

    Allis-Chalmers
    $11.00
    DJS2496
    Hydraulic position control vinyl decal for listed Allis Chalmers D Series models.Part Number: DJS2496FitsAllis Chalmers D10Allis Chalmers D12Allis Chalmers D14Allis Chalmers D15Allis Chalmers...
    Add to Cart
  • Allis-Chalmers Light Terminal, industrial black metal component with mounting screws and a metal bracket for electrical connection.

    Light Terminal

    Allis-Chalmers
    $6.75
    IH-475D
    Light terminal for listed tractor models.Part Number: IH-475DFitsAllis-Chalmers B, C, CA, D10, D12, D14, D15 (up to sn 9001), WC, WD, WD45, WF, RCAveryCase LA, SC, DC, 600, 900, 700, 800, 400, 500,...
    Add to Cart
  • Allis-Chalmers Oil Seal for Allis-Chalmers, Case, Ford, IH, John Deere - close-up view of oil seal with black rubber inner ring and yellow-brown outer ring for machinery lubrication.

    Oil Seal for Allis-Chalmers, Case, Ford, IH, John Deere

    Allis-Chalmers
    $15.75
    AB-1543D
    Oil seal for the listed Allis-Chalmers, Case, Ford, IH/Farmall, and John Deere applications. Verify fitment by model and notes before ordering.Part Number: AB-1543DFitsAllis Chalmers: PTO output...
    Add to Cart
  • Allis-Chalmers Gasket Paper Roll, 98 inches long, flat roll of gasket paper material

    Gasket Paper Roll 98" Long

    Allis-Chalmers
    $18.75
    AB-1844D
    Gasket paper roll for making general purpose gaskets. Not for high temperature applications.Part Number: AB-1844DFitsAllis Chalmers: VariousAvery: VariousCase: VariousCockshutt: VariousFord:...
    Add to Cart
  • Allis-Chalmers Battery Cable 13" (Non-Insulated) AB-405D, a braided metallic battery cable with eyelet connectors on both ends for tractor battery connection.

    Allis-Chalmers Battery Cable 13" Non-Insulated AB-405D

    Allis-Chalmers
    $21.75
    AB-405D
    Battery Cable AB-405DThis 13-inch non-insulated battery cable is a 2-gauge ground cable with straight terminals and 1/2-inch eyelet openings.Keep the important fitment and replacement details below...
    Add to Cart
  • Allis-Chalmers OEM Style Choke Rod Knob for Allis Chalmers D10 D12 D14 D15 D17, black round tractor control knob

    OEM Style Choke Rod Knob for Allis Chalmers D10 D12 D14 D15 D17

    Allis-Chalmers
    $6.75
    70228321
    OEM Style Choke Rod Knob for Allis Chalmers D10, D12, D14, D15, and D17. Verify the application notes and thread size before ordering.Part Number: 70228321FitsD10 (as a choke knob)D12 (as choke...
    Add to Cart
  • Allis-Chalmers Seat Shock Absorber Fits Monroe Seat, black automotive shock absorber for seat suspension.

    Seat Shock Absorber Fits Monroe Seat

    Allis-Chalmers
    $48.75
    IH-329D
    The only newly manufactured oil-filled seat shock available. Competing products use air shocks built for automotive suspension, not tractors.Direct-fit rear seat shock absorber for tractors equipped...
    Add to Cart
  • Allis-Chalmers Allis Chalmers D14 Vinyl Decal Set (w/ Oval Letters) - DJS143

    Allis Chalmers D14 Vinyl Decal Set, w/ Oval Letters

    Allis-Chalmers
    $82.00
    DJS143
    Vinyl decal set for Allis Chalmers D14 tractors with oval model letters. Listed for 1957-1959 D14 models.Part Number: DJS143FitsAllis Chalmers D14 with oval model letters, 1957-1959SpecsVinyl die cut...
    Add to Cart
