Allis Chalmers D14 Tractor Parts

About the Allis-Chalmers D14

The D14 opened the Allis-Chalmers D Series in 1957 as a new compact tractor for row-crop and general farm work. Its 149-cubic-inch four-cylinder engine was available for gasoline or LP gas, and the four-speed transmission could be paired with a transfer case for more gear choices. The D14 was equipped with the Power Director hand clutch, which gave the operator live PTO control without stopping the tractor.

Built through 1960, the D14 sits between the older CA and WD-era tractors and the D15 that followed it. The serial number table below can help identify the tractor's year.

Serial Number Reference

Serial number locations: The tractor serial number is stamped at the left front end of the torque tube. The engine serial number is on the rear left-hand side of the engine, behind the carburetor.

The table below shows the beginning tractor serial number for each Model D14 year:



1957-1958
Model D14 year Beginning serial number
1957 1,001
1958 9,400
1959-1959
Model D14 year Beginning serial number
1959 14,900
1960-1960
Model D14 year Beginning serial number
1960 21,800

Total production: 23,050 Model D14 tractors.

Allis-Chalmers D14 Paint Reference

For restoration planning, the Allis-Chalmers D14 is listed in the Allis-Chalmers tractor paint guide with the original paint references below.

Allis-Chalmers D14 paint reference by production period
Production period Metal Wheels Disc Chassis Trim
1929 through 1960 Persian Orange 1 Persian Orange 1 Persian Orange 1, Aluminum Persian Orange 1 Persian Orange 1, Aluminum grille

Paint placement can vary by production year, series, and equipment configuration.

Sort By:

Display Type:
Filters
  • Aftermarket 12V Distributor Hot Coil 55000 Volts Internally Resisted, black electrical coil component with mounting brackets and terminal connectors.

    12V Distributor Hot Coil 55000 Volts Internally Resisted

    Aftermarket
    $59.75
    AB-6158D
    12V distributor hot coil with 55,000 volts and internally resisted design. No external resistor required.Works with or without electronic ignition system.Part Number: AB-6158DFitsAllis Chalmers - B,...
  • Close-up product photo of a silver Allis-Chalmers tractor starter drive, with a dark toothed pinion gear at the left and a cylindrical metal housing extending to the right, on a white background. For D10, D12, D14, and D15 farm tractors.

    Starter Drive for Allis Chalmers D10 D12 D14 D15

    Allis-Chalmers
    $87.50
    70233295
    Part Number: 70233295Starter DriveStarter drive for the listed Allis Chalmers models below. For D10, D12, D14, and D15 tractors from 1961 and up.FitsAllis Chalmers D10 (1961 & up)Allis Chalmers D12...
  • A brass 90-degree elbow fitting with threaded ends, designed for fuel line connections to carburetors on Allis-Chalmers farm tractors.

    90 Degree Elbow Fitting for Fuel Line to Carburetor

    Allis-Chalmers
    $8.50
    35K403
    Part Number: 35K40390 Degree Elbow FittingThis 90 degree elbow fitting is used from the fuel line to the carburetor. It is listed for Allis-Chalmers D15 and D14.FitsAllis-Chalmers D14Allis-Chalmers...
  • Allis-Chalmers Universal Choke Cable 72"

    Universal Choke Cable 72"

    Allis-Chalmers
    $14.75
    AB-423D
    Universal choke cable with a 72" metal sheathed length.Cut to length. Can also be used as a stop cable for diesel engines. Various tractors, forklifts, and other applications using 72" or less cable...
  • Allis-Chalmers Brake Pedal Return Spring 70227700, black coiled metal spring with hooks on both ends

    Allis Chalmers Brake Pedal Return Spring 70227700

    Allis-Chalmers
    $14.75
    70227700
    Part Number: 70227700Allis Chalmers Brake Pedal Return SpringBrake pedal return spring for Allis Chalmers tractors. Used as a clutch pedal return spring on the D21.FitsAllis Chalmers D10Allis...
  • Image of a carburetor kit with various small parts, gaskets, springs, screws, and other components for Allis-Chalmers farm tractors, specifically models D14 and D15 Platinum.

    Allis-Chalmers D14 D15 Platinum Carburetor Kit

    Allis-Chalmers
    $62.75
    ACR7827
    Platinum carburetor repair kit for Allis-Chalmers D14 and D15 models with Marvel Schebler TSX844 and TSX815 (70234228) carburetors.Part Number: ACR7827FitsAllis Chalmers - D14, D15 (both with Marvel...
  • A flexible black fuel line with metal fittings on both ends, designed for Allis-Chalmers farm tractors D14 and D15.

    Allis Chalmers D14 D15 Fuel Line

    Allis-Chalmers
    $53.75
    70235559
    Fuel line for Allis Chalmers D14 and D15 gas-only models.Part Number: 70235559FitsAllis Chalmers D14Allis Chalmers D15Gas onlyReplaces / Cross Reference70235559235559NotesLOOK AT PART#'S 35K373 AND...
  • A bullet-style tail light assembly for Allis-Chalmers farm tractors, specifically models D14, D15, and D17. The tail light has a black casing, a red lens, and a green wire for electrical connection.

    Bullet Style Tail Light Assembly for Allis-Chalmers D14, D15, D17

    Allis-Chalmers
    $68.75
    AB-3023D
    Bullet style tail light assembly for listed Allis-Chalmers, AC Cotton Picker, John Deere, and JD Lawn & Garden applications.Part Number: AB-3023DFitsAllis Chalmers D14 (SN 19001 and up)Allis Chalmers...
  • Allis-Chalmers tractor governor assembly for distributor ignition, with a cast metal housing, large helical gear, and long shaft ending in a smaller gear. Fits Allis-Chalmers B, C, CA, IB, D10, D12, D14, and D15 tractors.

    Governor (Distributor Ignition) for Allis Chalmers B C CA IB D10 D12 D14 D15

    Allis-Chalmers
    $169.50
    ACR3534
    New replacement governor for tractors with distributor ignition.Fits Allis Chalmers B, C, CA, IB, D10, D12, D14, and D15.Part Number: ACR3534Replaces / Cross Reference70225349225349NotesPart Number:...
  • A battery hold down bracket set with various metal components and rubber washers, designed for Allis-Chalmers D14 and D15 farm tractors, not suitable for automobiles.

    Allis Chalmers D14 D15 Battery Hold Down Bracket

    Allis-Chalmers
    $48.75
    70228778
    Battery retainer / battery hold down bracket for select Allis Chalmers tractors. Supplied with J bolts and listed with replacement number 70228778.Part Number: 70228778FitsAllis Chalmers D14Allis...
  • Allis-Chalmers Red Glass Bullet Tail Light Lens Allis Chalmers International JD

    Red Glass Bullet Tail Light Lens

    Allis-Chalmers
    $17.75
    AC-123D
    Red Glass Bullet Tail Light Lens for select tractor applications.Use with bullet-style tail lights where listed.Part Number: AC-123DFitsAllis Chalmers: G, WD, WD45, B, C, CA, D10, D12 (up to sn...
  • Aftermarket 3 PT Lynch Pin, metallic pin with a circular ring for securing attachments in farming equipment.

    3 PT Lynch Pin

    Aftermarket
    $2.00
    MI-119D
    3 PT Lynch Pin for 3-point equipped tractors and implements using 7/16" diameter pins.Part Number: MI-119DFitsAllis ChalmersAveryCaseCockshuttFordIH / FarmallJDMassey FergusonMassey...
  • Allis-Chalmers Tachometer Drive Threaded Nipple 70228769, metal threaded fitting with hexagonal center for tachometer connection.

    Allis Chalmers Tachometer Drive Threaded Nipple 70228769

    Allis-Chalmers
    $18.75
    AC-1912D
    Tachometer drive threaded nipple for select Allis Chalmers tractors and industrial models. Threads into the governor housing on gas and LP models or the block on diesel models.Part Number:...
  • Allis-Chalmers Battery Cable 27 in. Insulated AB-419D, a black insulated cable with metal terminal connections at both ends.

    Allis-Chalmers Battery Cable 27 in. Insulated AB-419D

    Allis-Chalmers
    $23.75
    AB-419D
    Allis-Chalmers Battery Cable AB-419DInsulated battery cable, 27" long, with heavy-duty straight terminals.Item # AB-419D. If a supply issue occurs, this may be a 2 gauge cable.FitsAllis Chalmers,...
  • Black toothed fan belt for Allis-Chalmers B, C, IB, and D14 farm tractors, part 70207003, shown on a white background.

    Allis-Chalmers B C IB D14 Fan Belt | 70207003

    Allis-Chalmers
    $19.75
    70207003
    Part Number: 70207003 Allis-Chalmers Fan Belt Fan belt identified as item 70207003 for select Allis-Chalmers tractors. Fits B without Generator C without Generator IB without Electric Starting D14...
  • Assortment of engine gaskets and seals for Allis-Chalmers D10, D12, D14, D15, and D15II farm tractors, including a four-cylinder head gasket and various brown and gray engine gaskets.

    Allis Chalmers Engine Gasket Set D10 D12 D14 D15 D15II

    Allis-Chalmers
    $129.75
    AC-1949D
    Engine gasket set for select Allis Chalmers gas or LP applications. Fits the listed engine sizes and model qualifiers.Part Number: AC-1949DFitsD10D12D14I40 (all gas or LP with 138 and 149 CI...
  • Allis-Chalmers tractor side-nameplate hardware set, with silver domed rivets arranged beside round stainless retaining clips on a white background.

    Allis Chalmers Side Nameplate Rivets & Stainless Clips Set

    Allis-Chalmers
    $24.75
    DJS016
    Allis Chalmers side nameplate rivets and stainless clips set for select models.Part Number: DJS016FitsD10D12D14D15D17I40I400I60I600Specs14 aluminum rivets14 stainless steel clips
  • Allis-Chalmers TUBE ONLY 6.5 x 16 - WH-050D, black tractor tire tube with a curved shape and detailed tread pattern.

    Tube Only 6.5 x 16

    Allis-Chalmers
    $19.75
    WH-050D
    Tube only 6.5 x 16" for 5.50, 6.00, and 6.50 x 16" tires.Fits a range of tractor brands listed below and cross references to WHS050.Part Number: WH-050DFitsAllis ChalmersAveryCaseCockshuttFordIH /...
