About the Allis-Chalmers D14

The D14 opened the Allis-Chalmers D Series in 1957 as a new compact tractor for row-crop and general farm work. Its 149-cubic-inch four-cylinder engine was available for gasoline or LP gas, and the four-speed transmission could be paired with a transfer case for more gear choices. The D14 was equipped with the Power Director hand clutch, which gave the operator live PTO control without stopping the tractor.

Built through 1960, the D14 sits between the older CA and WD-era tractors and the D15 that followed it. The serial number table below can help identify the tractor's year.

Serial Number Reference

Serial number locations: The tractor serial number is stamped at the left front end of the torque tube. The engine serial number is on the rear left-hand side of the engine, behind the carburetor.

The table below shows the beginning tractor serial number for each Model D14 year:



1957-1958
Model D14 year Beginning serial number
1957 1,001
1958 9,400
1959-1959
Model D14 year Beginning serial number
1959 14,900
1960-1960
Model D14 year Beginning serial number
1960 21,800

Total production: 23,050 Model D14 tractors.

Allis-Chalmers D14 Paint Reference

For restoration planning, the Allis-Chalmers D14 is listed in the Allis-Chalmers tractor paint guide with the original paint references below.

Allis-Chalmers D14 paint reference by production period
Production period Metal Wheels Disc Chassis Trim
1929 through 1960 Persian Orange 1 Persian Orange 1 Persian Orange 1, Aluminum Persian Orange 1 Persian Orange 1, Aluminum grille

Paint placement can vary by production year, series, and equipment configuration.

Filter By

Sort By:

Display Type:
Filters
  • Allis-Chalmers TUBE ONLY 6.5 x 16 - WH-050D, black tractor tire tube with a curved shape and detailed tread pattern.

    Tube Only 6.5 x 16

    Allis-Chalmers
    $19.75
    WH-050D
    Tube only 6.5 x 16" for 5.50, 6.00, and 6.50 x 16" tires.Fits a range of tractor brands listed below and cross references to WHS050.Part Number: WH-050DFitsAllis ChalmersAveryCaseCockshuttFordIH /...
    Add to Cart
  • Allis-Chalmers D14 D15 Transmission Housing Gasket, black rubber gasket shape with bolt holes

    Allis Chalmers D14 D15 Transmission Housing Gasket

    Allis-Chalmers
    $16.75
    70233246
    Transmission housing to lift arm housing gasket for Allis Chalmers tractors.Part Number: 70233246FitsAllis Chalmers D14Allis Chalmers D15Replaces / Cross Reference70233246233246
    Add to Cart
  • Allis-Chalmers D10 D12 D14 D15 Brake Shoe Return Spring, coiled metal spring with hooks at both ends for brake system components.

    Allis Chalmers D10 D12 D14 D15 Brake Shoe Return Spring

    Allis-Chalmers
    $15.75
    AC-316D
    Part Number: AC-316DAllis Chalmers Brake Shoe Return SpringBrake shoe return spring for Allis Chalmers D10, D12, D14, and D15 tractors. Sold individually.FitsAllis Chalmers D10Allis Chalmers D12Allis...
    Add to Cart
  • Allis-Chalmers Flywheel Ring Gear | Allis Chalmers D10 D12 D14 93 Teeth | 233305 70233305

    Allis Chalmers D10 D12 D14 Flywheel Ring Gear 93 Teeth

    Allis-Chalmers
    $124.25
    70233305
    Flywheel ring gear with 93 teeth for listed Allis Chalmers applications.Part Number: 70233305FitsAllis Chalmers D10 (Prior to SN 3501)Allis Chalmers D12 (Prior to SN 3001)Allis Chalmers D14 (Prior to...
    Add to Cart
  • Allis-Chalmers Ammeter Amp Gauge (30-0-30)

    Ammeter Amp Gauge (30-0-30)

    Allis-Chalmers
    $19.75
    AB-109D
    Ammeter amp gauge with a 30-0-30 range, chrome bezel, and 2" diameter hole fitment.Fits the tractor models and applications listed below.Part Number: AB-109DFitsAllis Chalmers: D10, D12, D14, D15,...
    Add to Cart
  • Allis-Chalmers Delco Distributor Shaft Bushing & Shim Kit

    Delco Distributor Shaft Bushing & Shim Kit for Allis-Chalmers, Avery, Case, Cockshutt, Oliver, John Deere

    Allis-Chalmers
    $25.75
    AB-3007D
    Delco distributor shaft bushing & shim kit for the listed Allis-Chalmers and other equipment applications.Use the included bushing and shims for the applications shown below. The bushing needs to be...
    Add to Cart
  • Allis-Chalmers Metal Sheathed Choke Cable 47"

    Metal Sheathed Choke Cable 47"

    Allis-Chalmers
    $22.75
    JD-718D
    Metal sheathed choke cable with a 47" length and plastic knob.Cut to length. Thread length where it goes through the dash is 3/8".Part Number: JD-718DFitsAllis Chalmers - various modelsAvery -...
    Add to Cart
  • Allis-Chalmers Water Pump Housing Gasket, blue gasket for Allis Chalmers B, C, CA, IB, D10, D12, D14, D15 models, part number 70207832.

    Allis Chalmers B C CA IB D10 D12 D14 D15 Water Pump Gasket

    Allis-Chalmers
    $5.50
    70207832
    Part Number: 70207832Allis-Chalmers Water Pump Housing GasketWater pump housing gasket for Allis-Chalmers B, C, CA, IB, D10, D12, D14, and D15 models.FitsAllis-Chalmers BAllis-Chalmers...
    Add to Cart
  • Allis-Chalmers Distributor Hold Down Clamp, a metallic mechanical component used for securing distributor assemblies in agricultural or industrial machinery.

    Distributor Hold Down Clamp

    Allis-Chalmers
    $7.75
    AB-2523D
    Distributor hold down clamp for Delco distributor applications. Sold individually and used 2 per engine.Part Number: AB-2523DFitsAllis Chalmers - B, C, CA, D10, D12, D14, D15, D17, IB, WC, WD, WD45,...
    Add to Cart
  • Allis-Chalmers Bullet Tail Light Lens Plastic D14 D15 D17, red round tail light lens with concentric circles design

    Allis Chalmers Bullet Tail Light Lens Plastic D14 D15 D17

    Allis-Chalmers
    $21.75
    AC-220D
    Bullet tail light lens plastic for listed Allis Chalmers, AC Lawn and Garden, and John Deere applications.USA made.Part Number: AC-220DFitsAllis Chalmers - D14 (sn 19001 and up), D15, D17 - AC LAWN...
    Add to Cart
  • Allis-Chalmers Chrome Dash Light Cover, shiny metallic chrome dash light cover with a smooth, rounded top surface.

    Allis-Chalmers Chrome Dash Light Cover

    Allis-Chalmers
    $18.99
    JD-589CHD
    Chrome dash light cover for select Allis-Chalmers, John Deere, and MM tractors. This 1-1/4 inch diameter chrome cover is for 2-screw style dash lights.Part Number: JD-589CHDFitsAllis Chalmers: D10,...
    Add to Cart
  • Allis-Chalmers Battery Cable 9" Non-Insulated Ground Cable AB-411D, a braided metal ground cable with a ring terminal at one end for battery connections.

    Battery Cable 9" Non-Insulated Ground Cable AB-411D

    Allis-Chalmers
    $18.75
    AB-411D
    Battery Cable 9" Non-Insulated Ground CableHeavy-duty 2 gauge battery cable with straight terminals. This 9" non-insulated ground cable is listed for select tractor applications.FitsAllis Chalmers -...
    Add to Cart
  • Allis-Chalmers Grill Screen for Allis-Chalmers D10 D12 D14 D15 D17 D19, square metal grill screen with grid pattern.

    Grill Screen for Allis-Chalmers D10 D12 D14 D15 D17 D19

    Allis-Chalmers
    $87.50
    ATC9918
    Grill screen for Allis-Chalmers D Series tractors. Can be used for replacing 100 and 200 Series grill screens.Part Number: ATC9918FitsAllis Chalmers: D Series (Late), D10, D12, D14, D15, D17,...
    Add to Cart
  • Allis-Chalmers Allis Chalmers Side Nameplate Rivets & Steel Clips Set - DJS015

    Allis-Chalmers Side Nameplate Rivets & Steel Clips Set

    Allis-Chalmers
    $19.75
    DJS015
    Part Number: DJS015Allis-Chalmers Side Nameplate Rivets & Steel Clips SetSet includes 14 aluminum rivets and 14 steel clips. For select Allis-Chalmers tractor side nameplates...
    Add to Cart
  • Allis-Chalmers Battery Cable 21" (Insulated) - AB-417D, black insulated battery cable with metal terminal end for connecting to batteries.

    Battery Cable 21" Insulated AB-417D

    Allis-Chalmers
    $19.75
    AB-417D
    Battery Cable 21" Insulated - AB-417D21-inch insulated battery cable with heavy-duty straight terminals and 2 gauge construction.Replacement for AM349T.FitsAllis Chalmers - variousCase -...
    Add to Cart
  • Allis-Chalmers 12 Volt Chrome Bullet Style Tail Light Assembly

    Allis-Chalmers 12 Volt Chrome Bullet Style Tail Light Assembly

    Allis-Chalmers
    $29.00
    AC-099D
    12 volt chrome bullet style tail light assembly for select Allis-Chalmers and John Deere models. It is a 1 wire 12 volt chrome bullet style tail light assembly with a plastic lens.Part Number:...
    Add to Cart
  • Allis-Chalmers Water Temperature Gauge, industrial water temperature meter with 130-280 degree range, with metal mounting and coiled sensor cable.

    Allis-Chalmers Water Temperature Gauge 130-280 Degree Range

    Allis-Chalmers
    $26.75
    UTG25
    Part Number: UTG25OverviewWater temperature gauge with a 130-280 degree range. Dash mount design with block fitting and chrome bezel included.Specs130-280 degree rangeDash mountIncludes block...
    Add to Cart
  • Allis-Chalmers UNIVERSAL STEERING JOINTS REPAIR KIT Allis Chalmers D14 D15 D17 D19 70228906

    Universal Steering Joints Repair Kit for Allis-Chalmers D14 D15 D17 D19

    Allis-Chalmers
    $123.00
    70228906
    Universal Steering Joints Repair Kit for select Allis-Chalmers tractors.Fits 7/8" (0.875) dia shaft both ends and includes yokes, pins, and grease fitting.Part Number: 70228906FitsAllis Chalmers -...
    Add to Cart
