Allis Chalmers D14 Tractor Parts

About the Allis-Chalmers D14

The D14 opened the Allis-Chalmers D Series in 1957 as a new compact tractor for row-crop and general farm work. Its 149-cubic-inch four-cylinder engine was available for gasoline or LP gas, and the four-speed transmission could be paired with a transfer case for more gear choices. The D14 was equipped with the Power Director hand clutch, which gave the operator live PTO control without stopping the tractor.

Built through 1960, the D14 sits between the older CA and WD-era tractors and the D15 that followed it. The serial number table below can help identify the tractor's year.

Serial Number Reference

Serial number locations: The tractor serial number is stamped at the left front end of the torque tube. The engine serial number is on the rear left-hand side of the engine, behind the carburetor.

The table below shows the beginning tractor serial number for each Model D14 year:



1957-1958
Model D14 year Beginning serial number
1957 1,001
1958 9,400
1959-1959
Model D14 year Beginning serial number
1959 14,900
1960-1960
Model D14 year Beginning serial number
1960 21,800

Total production: 23,050 Model D14 tractors.

Allis-Chalmers D14 Paint Reference

For restoration planning, the Allis-Chalmers D14 is listed in the Allis-Chalmers tractor paint guide with the original paint references below.

Allis-Chalmers D14 paint reference by production period
Production period Metal Wheels Disc Chassis Trim
1929 through 1960 Persian Orange 1 Persian Orange 1 Persian Orange 1, Aluminum Persian Orange 1 Persian Orange 1, Aluminum grille

Paint placement can vary by production year, series, and equipment configuration.

Filter By

Sort By:

Display Type:
Filters
  • Allis-Chalmers Bottom Seat Cushion for D10 D12 D14 D15 D17 D19 D21, black and white upholstered tractor seat cushion.

    Allis-Chalmers Bottom Seat Cushion for D10 D12 D14 D15 D17 D19 D21

    Allis-Chalmers
    $249.75
    AC-223D
    Restoration quality bottom seat cushion for select Allis-Chalmers tractors. Cushion is embossed like original and made in the USA.Part Number: AC-223DFitsD10D12D14D15D17D19D21170, 175, 180, 185, 190,...
    Add to Cart
  • Allis-Chalmers REAR TIRE INNER TUBE VALVE - AB-384D

    Rear Tire Inner Tube Valve for Tractor Tubes with External Threads

    Allis-Chalmers
    $11.75
    AB-384D
    Rear tire inner tube valve for tractor tubes with external threads.Old style air/water valve, sold individually.Part Number: AB-384DFitsAllis ChalmersAveryCaseCockshuttFordIH / FarmallJohn...
    Add to Cart
  • Allis-Chalmers Universal 3 Position Push/Pull Light Switch - JD-631D, electrical switch with metal and plastic components and a black toggle handle.

    Universal 3 Position Push/Pull Light Switch - JD-631D

    Allis-Chalmers
    $14.75
    JD-631D
    Universal 3 Position Push/Pull Light Switch - JD-631DThis universal 3 position push/pull light switch is rated for 15 amps and uses 5 terminals. It includes the black plastic knob.FitsAllis...
    Add to Cart
  • Allis-Chalmers Auxiliary Male 2 Pin Connector Plug, metallic connector with two gold pins and hexagonal nut on top, used for electrical connections.

    Auxiliary Male 2 Pin Connector Plug

    Allis-Chalmers
    $29.75
    AB-1868D
    Auxiliary Male 2 Pin Connector Plug with threaded cable grip and plated brass pins.For 12-18 gauge wire. Wires must be soldered or crimped.Part Number: AB-1868DFitsAllis Chalmers - variousCase -...
    Add to Cart
  • Allis-Chalmers Allis Chalmers 6 Volt Bullet Tail Light, vintage vehicle accessory with silver housing, red lens, and white wiring

    Allis Chalmers 6 Volt Bullet Tail Light

    Allis-Chalmers
    $45.75
    AC-264V6D
    6 volt bullet tail light for select Allis Chalmers and John Deere tractors. Restoration quality, with 6-volt bulb included and a red glass lens.Part Number: AC-264V6DFitsAllis Chalmers: B, C, CA, G,...
    Add to Cart
  • Allis-Chalmers Allis Chalmers Clutch Kit B C CA IB D10 D12 D14 D15 New

    Allis Chalmers Clutch Kit for B, C, CA, D14, D15, H3, HD3, I500, I600, IB, D10, D12

    Allis-Chalmers
    $229.95
    AC-2470D
    Allis Chalmers Clutch Kit for B, C, CA, D14, D15, H3, HD3, I500, I600, IB, D10, and D12. Replacement for 70230099, 70247743, 70228926, 70247744, 70231976, 206968, 70232239, 70247745, 70236122,...
    Add to Cart
  • Allis-Chalmers Back Rest Seat Cushion for D10 D12 D14 D15 D17 D19 D21, black and white tractor seat cushion with ergonomic design.

    Allis-Chalmers Back Rest Seat Cushion for D10 D12 D14 D15 D17 D19 D21

    Allis-Chalmers
    $219.50
    AC-222D
    Restoration quality back rest seat cushion for select Allis-Chalmers tractors. Cushion is embossed like original and made in the USA.Part Number: AC-222DFitsD10D12D14D15D17D19D21170, 175, 180, 185,...
    Add to Cart
  • Allis-Chalmers Fuel Bail Assembly (Short Bowl), metal fuel bail with handle, used for agricultural machinery.

    Fuel Bail Assembly (Short Bowl)

    Allis-Chalmers
    $8.00
    AB-563D
    Fuel Bail Assembly (Short Bowl) for Allis-Chalmers and other listed tractor models. New part.Part Number: AB-563DFitsAllis Chalmers: B, IB, C, CA, D10, D12, D14, D15 Gas (up to sn 9001), D17 Gas (up...
    Add to Cart
  • Allis-Chalmers ALTERNATOR PULLEY 2-1/2" OD 5/8" belt width

    Allis-Chalmers Alternator Pulley 2-1/2" OD 5/8" Belt Width

    Allis-Chalmers
    $23.95
    AB-495D
    Alternator pulley for the listed tractor applications. Same applications as part number AB-418D alternator.Part Number: AB-495DFitsAllis ChalmersCaseCockshuttFordIH / FarmallJohn DeereMassey...
    Add to Cart
  • Allis-Chalmers Side Name Plate Rivet AC-1567D, metallic rivet for attaching the side name plate on Allis-Chalmers equipment.

    Allis-Chalmers Side Name Plate Rivet AC-1567D

    Allis-Chalmers
    $0.95
    AC-1567D
    Allis-Chalmers side name plate rivet for securing name plates and emblems on select tractors and cotton pickers. Sold individually.Replaces 70234173V, 70234173, and 234173.FitsAllis-Chalmers...
    Add to Cart
  • Allis-Chalmers Persian Orange #1 Emblem Allis Chalmers Steering Wheel and Front Nose Emblem

    Persian Orange #1 Emblem for Allis-Chalmers Steering Wheel and Front Nose

    Allis-Chalmers
    $34.00
    A9900
    Persian Orange #1 Emblem for Allis-Chalmers steering wheel and front nose applications.Die cast, chromed, painted Persian #1 background.Part Number: A9900FitsAllis Chalmers - ED40, D10, D12, D14,...
    Add to Cart
  • Allis-Chalmers Raincap 2" - 2 3/16" ID, gray raincap for pipes with a locking mechanism and bolt fastening.

    Allis-Chalmers Raincap 2" - 2 3/16" ID

    Allis-Chalmers
    $12.50
    ACR1800
    Raincap with 2" - 2 3/16" ID. Listed for select Allis-Chalmers and other tractor brands below.Part Number: ACR1800FitsAllis ChalmersCaseCockshutt: CO-OP E2Cockshutt 30FordIH / FarmallJohn...
    Add to Cart
  • Allis-Chalmers Allis Chalmers Left Hand Side Panel with Choke Slot D14 D15

    Allis-Chalmers Left Hand Side Panel with Choke Slot D14 D15

    Allis-Chalmers
    $67.50
    ACR4025
    Left-hand side panel with choke slot for Allis Chalmers tractors.Part Number: ACR4025FitsAllis Chalmers: D14 (up to sn 19000)Allis Chalmers: D15 Series I (up to sn 9000)Allis Chalmers: I60Allis...
    Add to Cart
  • Allis-Chalmers Battery Retainer J-Bolt (Pair) IH-721D, black metal battery retainer bolts with wing nut threads and hooks for securing tractor batteries.

    Battery Retainer J-Bolt Pair IH-721D

    Allis-Chalmers
    $9.75
    IH-721D
    Battery Retainer J-Bolt PairThis IH-721D battery retainer J-bolt set comes as a pair. These are universal battery J-bolts and measure 5/16-18 NC x 10.750" long.FitsAllis-Chalmers: variousAvery:...
    Add to Cart
  • Allis-Chalmers Tie Rod Dust Boot, black rubber dust cover for allis chalmers G 70800442 tractor parts.

    Allis-Chalmers Tie Rod Dust Boot FD-336D 70800442

    Allis-Chalmers
    $4.95
    FD-336D
    Allis-Chalmers Tie Rod Dust Boot FD-336D 70800442This tie rod dust boot is listed as serviceable for Allis-Chalmers G and includes universal applications shown below. Dimensions and cross references...
    Add to Cart
  • Allis-Chalmers AMMETER (AMP) GAUGE, 60-0-60 - AB-466D

    AMMETER (AMP) GAUGE, 60-0-60

    Allis-Chalmers
    $19.75
    AB-466D
    Ammeter (amp) gauge with a 60-0-60 range, chrome bezel, and no logo.Fits most tractors equipped with an alternator and a 2" diameter hole.Part Number: AB-466DFitsAllis ChalmersAveryCaseCockshuttFord
    Add to Cart
  • Allis-Chalmers Straight Fitting For Sediment Bowl To Fuel Line Allis Chalmers D14,D15,WD45

    Straight Fitting for Sediment Bowl to Fuel Line

    Allis-Chalmers
    $4.25
    35K373
    Part Number: 35K373Straight Sediment Bowl Fuel Line FittingStraight brass fitting for the sediment bowl fuel line.FitsAllis-Chalmers D14Allis-Chalmers D15Allis-Chalmers WD45Specs1/4" flare to 1/8"...
    Add to Cart
  • Allis-Chalmers Air Cleaner Cap, black cylindrical engine air filter cover with part numbers 70225860 and 70242072

    Allis-Chalmers Air Cleaner Cap 70225860 70242072

    Allis-Chalmers
    $21.75
    ACR0578
    Air cleaner cap for Allis-Chalmers CA (late), D10, D12, and D14 tractors.Replacement cap with the following measurements:I.D.: 1-5/8 in.O.D. of cap: 4 in.Overall height: 1-3/8 in.Part Number:...
    Add to Cart
