Allis Chalmers D17 Tractor Parts

About the Allis-Chalmers D17

Introduced in 1957, the D17 moved the D Series into the larger row-crop tractor class. It used the Power Director transmission and live PTO, so the operator could shift between ranges with a hand lever while keeping PTO-driven equipment running.

The D17 was built through 1967 in Series I, Series II, Series III, and Series IV versions. Gasoline, LP-gas, and diesel engines were offered during the production run, and the serial number table shows where each series begins.

Serial Number Reference

Serial number locations: The tractor serial number is stamped on the left-front end of the torque housing. The gasoline engine serial number is on the rear left-hand side of the engine block behind the carburetor; diesel engine numbers are on the top left-hand side of the engine block.

The table below shows the beginning tractor serial number for each Model D17 year and series:



1957-1960
Model D17 year Beginning serial number
1957 - Series I 1,001
1958 - Series I 4,300
1959 - Series I 16,500
1960 - Series I 28,200
1960 - Series II 32,001
1961-1964
Model D17 year Beginning serial number
1961 - Series II 33,100
1962 - Series II 38,070
1962 - Series III 42,001
1963 - Series III 65,001
1964 - Series III 70,611
1964-1967
Model D17 year Beginning serial number
1964 - Series IV 75,001
1965 - Series IV 77,090
1966 - Series IV 80,533
1967 - Series IV 86,061

Total production: 84,914 Model D17 tractors (51,598 gas and 12,284 diesel; LP-gas production is unknown).

Filter By

Sort By:

Display Type:
Filters
  • Allis-Chalmers UNIVERSAL STEERING JOINTS REPAIR KIT Allis Chalmers D14 D15 D17 D19 70228906

    Universal Steering Joints Repair Kit for Allis-Chalmers D14 D15 D17 D19

    Allis-Chalmers
    $123.00
    70228906
    Universal Steering Joints Repair Kit for select Allis-Chalmers tractors.Fits 7/8" (0.875) dia shaft both ends and includes yokes, pins, and grease fitting.Part Number: 70228906FitsAllis Chalmers -...
    Add to Cart
  • Allis-Chalmers Deluxe Steering Wheel Spinner WSDX1

    Deluxe Steering Wheel Spinner

    Allis-Chalmers
    $17.75
    WSDX1
    Deluxe Steering Wheel Spinner for various tractor models.Part Number: WSDX1FitsAllis Chalmers - VariousAvery - VariousCase - VariousCockshutt - VariousFord - VariousIH / Farmall - VariousJohn Deere -...
    Add to Cart
  • Allis-Chalmers Washer, Needle & Seat Main Adjustment Allis Chalmers | 70226466

    Washer, Needle & Seat Main Adjustment for Allis-Chalmers

    Allis-Chalmers
    $7.25
    70226466
    Washer for Needle & Seat Main Adjustment for select Allis-Chalmers equipment.Includes 1 washer.Part Number: 70226466FitsAllis Chalmers - WD, WD45, D15, D17, 170, 175AC Combine - EReplaces / Cross...
    Add to Cart
  • Allis-Chalmers Allis Chalmers Carburetor to Governor Link Rod WC WF WD WD45 D17 170 175 - 70237203

    Allis Chalmers Carburetor to Governor Link Rod

    Allis-Chalmers
    $27.25
    70237203
    Carburetor to Governor Link Rod for the listed Allis Chalmers Tractors, AC Power Units, and Gleaner models. Part Number: 70237203 Fits Allis Chalmers - WC, WF, WD, WD45, D17 (GAS, LP), (170, 175...
    Add to Cart
  • Allis-Chalmers Allis Chalmers D17 Series I II Restoration Quality Wiring Harness

    Allis-Chalmers D17 Series I & II Wiring Harness

    Allis-Chalmers
    $289.50
    AC-3850D
    Replacement wiring harness for Allis-Chalmers D17 gas tractors. For original generator systems and supplied with light wires and instructions.Part Number: AC-3850DFitsAllis Chalmers - D17 gas (Series...
    Add to Cart
  • Allis-Chalmers External Hydraulic Lift Arm Cylinder Seal Kit Allis Chalmers 170 175 180 190 190XT D17 D19

    Allis-Chalmers External Hydraulic Lift Arm Cylinder Seal Kit

    Allis-Chalmers
    $45.75
    AC-3761D
    Seal kit for Allis-Chalmers external hydraulic lift arm cylinders. Use the fitment and cylinder measurements below to verify your application before ordering.Part Number: AC-3761DFitsAllis Chalmers -...
    Add to Cart
  • Allis-Chalmers Sediment Bowl Assembly Allis Chalmers B C CA IB RC D14 D15 D17 D19

    Sediment Bowl Assembly for Allis-Chalmers B, C, CA, IB, RC, D14, D15, D17, D19

    Allis-Chalmers
    $29.75
    AB-092D
    Sediment Bowl Assembly for Allis-Chalmers B, C, CA, IB, RC, D14, D15, D17, and D19. Confirm the fuel bowl style and outlet before ordering.Includes a shallow bowl with a 90 degree outlet only.Part...
    Add to Cart
  • Allis-Chalmers Fuel Line Compression Fitting 5/16" Line to 1/8" Pipe, metallic fitting with threaded end for fuel line connection.

    Fuel Line Compression Fitting 5/16" Line to 1/8" Pipe - Various Models

    Allis-Chalmers
    $3.75
    516FITTING
    Fuel line compression fitting for various Allis-Chalmers models. Connects 5/16" line to 1/8" pipe and is used on sediment bowls in most applications.Part Number: 516FITTINGFitsAllis Chalmers -...
    Add to Cart
  • Allis-Chalmers Dip Stick Gage Bushing - Allis Chalmers CA B C WC WF WD WD45 D10 D12 D14 D15 D17 D19

    Dip Stick Gage Bushing - Allis-Chalmers CA B C WC WF WD WD45 D10 D12 D14 D15 D17 D19

    Allis-Chalmers
    $28.75
    70211825
    Dip Stick Gage Bushing for listed Allis-Chalmers and AC Miscellaneous models.Part Number: 70211825FitsAllis Chalmers - CA, B, IB, C, WC, WF, WD, WD45, D10, D12, D14, D15, D17, D19AC Miscellaneous -...
    Add to Cart
  • Allis-Chalmers Allis Chalmers WD45 D17 Carburetor TSX464 TSX561 TSX773

    Allis-Chalmers WD45 D17 Carburetor TSX464 TSX561 TSX773

    Allis-Chalmers
    $349.75
    ACR7934
    Brand new Marvel Schebler style carburetor for Allis-Chalmers WD45 and D17 up to SN 42000. Comes with a mounting gasket and the listed specifications below.Part Number: ACR7934FitsAllis Chalmers...
    Add to Cart
  • Allis-Chalmers Muffler Bracket | Allis Chalmers WC WD WD45 D17

    Muffler Bracket - Allis-Chalmers WC WD WD45 D17

    Allis-Chalmers
    $9.75
    AC-1762D
    Muffler bracket for Allis-Chalmers Styled WC, WD, WD45, and Early D17 gas.Part Number: AC-1762DFitsAllis Chalmers Styled WCAllis Chalmers WDAllis Chalmers WD45Allis Chalmers Early D17 gasB, C, CA, RC...
    Add to Cart
  • Allis-Chalmers Brake Pin Puller Removal Tool Allis Chalmers D17 WD WD45

    Brake Pin Puller Removal Tool for Allis-Chalmers WD, WD45, D17

    Allis-Chalmers
    $78.75
    AC-3558D
    Brake Pin Puller Removal Tool for Allis-Chalmers WD, WD45, WD45 (diesel), and D17 (up to SN: 42000).Part Number: AC-3558DFitsAllis-Chalmers WDAllis-Chalmers WD45Allis-Chalmers WD45...
    Add to Cart
  • Allis-Chalmers Allis Chalmers Brake Band Return Spring D17 170-185 250447 70250447

    Allis Chalmers D17, 170, 175, 180, 185 Brake Band Return Spring

    Allis-Chalmers
    $7.75
    70250447
    Allis Chalmers D17, 170, 175, 180, 185Brake Band Return SpringPart Number: 70250447FitsD17170175180185Replaces / Cross Reference70250447250447Notes4 used per tractorOrdering NotesCheck
    Add to Cart
  • Allis-Chalmers Allis Chalmers Brake Disc Return Spring D17-D21 170-200 70250435 250435

    Allis-Chalmers Brake Disc Return Spring

    Allis-Chalmers
    $7.75
    70250435
    Brake disc return spring for select Allis-Chalmers tractors, AC Gleaner combines, and AC miscellaneous equipment.Part Number: 70250435FitsAllis Chalmers - D17, D19, D21, 170, 175, 180, 185, 190,...
    Add to Cart
  • Allis-Chalmers Platinum Carburetor Kit - Allis Chalmers WD45, D17 - Marvel Schebler TSX464, TSX561, TSX773, TSX871

    Platinum Carburetor Kit for Allis Chalmers WD45 D17

    Allis-Chalmers
    $62.75
    ACR7823
    Platinum Carburetor Kit for Allis Chalmers WD45 and D17 with Marvel Schebler carburetors.Includes repair components for the listed carburetor applications, with note to reuse the old choke shaft on...
    Add to Cart
  • Allis-Chalmers Marvel Schebler Carburetor Nozzle Allis Chalmers WD45 D17 | 70226460

    Marvel Schebler Carburetor Nozzle for Allis Chalmers WD45 D17

    Allis-Chalmers
    $24.00
    AC47-449
    Marvel Schebler carburetor nozzle for select Allis-Chalmers tractors.Part Number: AC47-449FitsWD45D17 (All Series)Marvel Schebler carburetors: TSX561, TSX464, TSX773, TSX871Replaces / Cross...
    Add to Cart
  • Allis-Chalmers Needle & Seat Assembly Main Jet Marvel Schebler Allis Chalmers WD45 D17 | 70226479

    Needle & Seat Assembly Main Jet for Allis Chalmers WD45 D17

    Allis-Chalmers
    $32.25
    AC43-671
    Needle & seat assembly main jet for select Allis-Chalmers tractors.Part Number: AC43-671FitsWD45D17 (All Series)Marvel Schebler carburetors: TSX561, TSX464, TSX773, TSX871Replaces / Cross...
    Add to Cart
  • Allis-Chalmers Gasket

    Gasket for Allis Chalmers, International, John Deere, Massey Harris, Minneapolis Moline

    Allis-Chalmers
    $4.00
    AB-3352D
    Gasket for select Allis-Chalmers, International, John Deere, Massey Harris, and Minneapolis Moline applications.Part Number: AB-3352DFitsAllis Chalmers - B, C, CA, D14, D17, U, WC, WD, WF (Auxiliary...
    Add to Cart
